| Electrical Durability | 5000 cycle; 60 cycles per hour |
| Mechanical Durability | 20000 cycle; 120 cycles per hour |
| Power Loss | at Rated Operating Conditions per Pole 41 W |
| Rated Current (In) | 630 A |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 70 kA; (230 V AC) 70 kA; (380 V AC) 36 kA; (400 V AC) 36 kA; (415 V AC) 36 kA; (440 V AC) 30 kA; (500 V AC) 25 kA; (690 V AC) 20 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 70 kA; (230 V AC) 70 kA; (380 V AC) 36 kA; (400 V AC) 36 kA; (415 V AC) 36 kA; (440 V AC) 30 kA; (500 V AC) 25 kA; (690 V AC) 20 kA |
| Rated Uninterrupted Current (Iu) | 630 A |
| Release | PR221DS-LS/I |
| Release Type | EL |
| Short-Circuit Performance Level | N |
| Sub-type | T5 |
| Terminal Connection Type | Fixed Circuit-Breakers; Front |
| Test Voltage Max (Utest) | 3500 V |
| Test Voltage at Industrial Frequency for 1 Minute | 3500 V |
Standards: IEC
CE Declaration: 9AKK106713A5539
Data Sheet: 1SDC210004D0203
Product Main Type: SACE Tmax T
Product Class: Moulded Case Circuit Breakers
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 1SDA054396R1 |
| series | SACE Tmax T5 |
| catalog_type | T5N 630 PR221DS-LS/I In=630 3p F F |
| rated_current_A | 630 |
| number_of_poles | 3 |
| rated_voltage_Vac | 690 |
| breaking_capacity_Icu_kA_at_400V | 36 |
| trip_unit | PR221DS-LS/I electronic |
| mounting | fixed |
| terminals | front |
