ABB AF50 AF Series 3-Pole Contactor with 1 NO Auxiliary Contacts
| Parameter | Value |
|---|---|
| Rated Operational Voltage | 690 V (Main Circuit) |
| Rated Control Circuit Voltage | 100...250 V AC / 100...250 V DC |
| Rated Frequency | 50/60 Hz |
| Conventional Thermal Current (Ith) | 65 A @ 40°C (free air) |
| Rated Insulation Voltage | 690 V |
| Impulse Withstand Voltage | 6 kV |
| Number of Main Contacts NO | 3 |
| Number of Main Contacts NC | 0 |
| Auxiliary Contacts | 1 NO |
| Category | Conditions | Value |
|---|---|---|
| AC-1 | 690V, 40°C | 60 A |
| AC-1 | 690V, 60°C | 50 A |
| AC-3 | 380/400V, 55°C | 37 A |
| AC-3 | 440V, 55°C | 37 A |
| AC-3 | 500V, 55°C | 32 A |
| AC-3 | 690V, 55°C | 23 A |
| UL/CSA General Use | 600V AC | 60 A |
| Voltage | Power |
|---|---|
| 220/230/240 V | 10.2 kW |
| 380/400 V | 18.5 kW |
| 415 V | 19.2 kW |
| 440 V | 20.4 kW |
| 500 V | 23.1 kW |
| 690 V | 31.9 kW |
| Parameter | Value |
|---|---|
| Dimensions (W×D×H) | 55 × 108 × 90 mm |
| Net Weight | 0.71 kg |
| Terminal Type | Screw Terminals |
| Main Connection | Rigid 6...35 mm² / Flexible 4...35 mm² |
| Max Operating Altitude | 3000 m |
| Degree of Protection | IP20 / IP10 (main terminals) |
| Mounting | DIN rail (35mm) or screw |
| Standard | Details |
|---|---|
| IEC / EN Standards | IEC/EN 60947-1, IEC/EN 60947-4-1 |
| UL Listed | UL 508 |
| CSA Certified | CSA C22.2 No. 14 |
| RoHS | Compliant per EU Directive 2011/65/EU |
| Marine / Railway | IEC 60077, EN 50155, IEC 61373 (as applicable) |
| Climatic Withstand | Category B per IEC 60947-1 Annex Q |
| Operating Temperature | -40°C to +70°C (without O/L relay) / -25°C to +60°C (with O/L relay) |
| Max Switching Freq. | AC-3: 1200 cycles/hr | Mechanical: 3600 cycles/hr |
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 1SBL281024R8010 |
| series | UA30-30-10RA |
| product_type | 3-pole capacitor-duty contactor with inrush resistor |
| number_of_poles | 3P (3 NO main) |
| rated_operational_current_AC3_400V | capacitor switching |
| motor_power_AC3_400V | ~27.5 kvar |
| rated_operational_current_AC1 | — |
| rated_insulation_voltage | 690 V (IEC) |
| coil_control_voltage | 220-230 V 50 Hz / 230-240 V 60 Hz AC |
| built_in_auxiliary_contacts | 1 NO built-in auxiliary |
| terminal_type | Screw terminals |
Source: datasheet / product page
