NFC80E Contactor Relay
| General | |
|---|---|
| Product Type | Contactor Relay |
| Model Designation | NFC80E |
| Number of Poles | 8 |
| Contact Configuration | 2 NO + 2 NC |
| Terminal Type | Screw Terminals |
| Electrical Ratings | |
| Rated Operational Voltage | 690 V AC |
| Rated Insulation Voltage (Ui) | 690 V (IEC) / 600 V (UL/CSA) |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Conventional Free-air Thermal Current (Ith) | 16 A (acc. IEC 60947-5-1) |
| Rated Operational Current AC-15 (240 V) | 4 A |
| Rated Operational Current DC-13 (24 V) | 6 A / 144 W |
| Coil | |
| Rated Control Circuit Voltage (Uc) | 50/60 Hz & 20...130 V DC |
| Coil Technology | Electronic — wide voltage range |
| Physical | |
| Dimensions (W × H × D) | 45 × 86 × 110.5 mm |
| Weight | 0.35 kg |
| Degree of Protection | IP20 |
| Mounting | DIN Rail (TH35-15/35x7.5) or Screw Mounting |
| Operating Temperature | -40 ... +70 °C |
| Switching | |
| Max Electrical Switching Freq. AC-15 | 1200 cycles/hour |
| Max Electrical Switching Freq. DC-13 | 900 cycles/hour |
| Mechanical Switching Frequency | 6000 cycles/hour |
| Standards | IEC/EN 60947-5-1, UL 508, CSA C22.2 No. 14 |
| RoHS | Compliant (EU Directive 2011/65/EU) |
| UL/CSA | Listed — cURus |
| CE Marking | Yes — Low Voltage Directive |
| Condition | New Surplus Packaging |
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 1SBH141001R8044 |
| ABB_type_designation | N44E |
| poles | 8-pole |
| contacts | 4 NO + 4 NC |
| rated_insulation_voltage_Ui | 690 V |
| rated_control_circuit_voltage | 220-230 V 50 Hz / 230-240 V 60 Hz AC (laminated magnetic circuit) |
| rated_operational_current_AC-1 | 16 A |
| protection_degree | IP20 |
| standards | IEC 60947-5-1 |
| terminal_type | Screw terminals |
| mounting | DIN rail TH35 |
Source: datasheet / product page
