ESB16 Installation Contactor (Hum-free, AC/DC)
| General | |
|---|---|
| Product Type | Installation Contactor (Hum-free, AC/DC) |
| Model Designation | ESB16 |
| Number of Main Poles | 2 |
| Auxiliary Contacts | 1 NO + 1 NC |
| Terminal Type | Screw Terminals |
| Electrical Ratings | |
| Rated Operational Current AC-1 / AC-7a | 16 A |
| Rated Operational Current AC-3 @ 230V | 6 A |
| Rated Operational Power AC-1 @ 230V | 0.9 kW |
| Rated Operational Voltage | 250 V AC (ESB16/20) or 400 V AC (ESB25+) |
| Rated Insulation Voltage (Ui) | 400 V (IEC 60947-4-1) / 500 V |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Coil | |
| Rated Control Circuit Voltage (Uc) | 24 V AC/DC |
| Coil Technology | AC/DC hum-free coil |
| Physical | |
| Dimensions (W × H × D) | 17.8 × 85 × 65 mm |
| Weight | 0.14 kg |
| Degree of Protection | IP20 |
| Mounting | DIN Rail (35 mm, System pro M compatible) |
| Operating Temperature | -25 ... +55 °C |
| Durability | |
| Electrical Durability AC-1 | 150,000 cycles |
| Electrical Durability AC-3 | 100,000 cycles |
| Mechanical Durability | 1,000,000 cycles |
| Standards | IEC/EN 60947-1, IEC/EN 60947-4-1, IEC/EN 61095, UL 508, CSA C22.2 No. 14 |
| RoHS | Compliant (EU Directive 2011/65/EU) |
| UL/CSA | Listed |
| CE Marking | Yes — Low Voltage Directive & EMC Directive |
| Condition | New Surplus Packaging |
Warranty: 12-month seller warranty provided by SHLY-PLC. See our Return Policy for coverage and claims.
A: Orders are processed within 2-4 business days after payment confirmation. Standard delivery: 5-8 business days to the United States and Canada. Express available (2–4 business days).
A: Sold by SHLY-PLC, an independent distributor. New surplus stock; condition and compatibility confirmed on request.
| converted_model | 1SBE111111R0611 |
| type | ESB16-11N-06 |
| rated_operational_current | 16 A |
| number_of_poles | 2P |
| contact_configuration | 1 NO + 1 NC |
| control_coil_voltage | 230 V AC/DC |
| power_rating | 3.7 kW |
| rated_operational_voltage_main | 220...240 V AC / 220 V DC |
| mounting | DIN rail TH35 |
| usage_category | AC-7a / household & installation |
Source: datasheet / product page
