ESB16 Installation Contactor (Hum-free, AC/DC)
| General | |
|---|---|
| Product Type | Installation Contactor (Hum-free, AC/DC) |
| Model Designation | ESB16 |
| Number of Main Poles | 2 |
| Auxiliary Contacts | 2 NO |
| Terminal Type | Screw Terminals |
| Electrical Ratings | |
| Rated Operational Current AC-1 / AC-7a | 16 A |
| Rated Operational Current AC-3 @ 230V | 6 A |
| Rated Operational Power AC-1 @ 230V | 0.9 kW |
| Rated Operational Voltage | 250 V AC (ESB16/20) or 400 V AC (ESB25+) |
| Rated Insulation Voltage (Ui) | 400 V (IEC 60947-4-1) / 500 V |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Coil | |
| Rated Control Circuit Voltage (Uc) | 24 V AC/DC |
| Coil Technology | AC/DC hum-free coil |
| Physical | |
| Dimensions (W × H × D) | 17.8 × 85 × 65 mm |
| Weight | 0.14 kg |
| Degree of Protection | IP20 |
| Mounting | DIN Rail (35 mm, System pro M compatible) |
| Operating Temperature | -25 ... +55 °C |
| Durability | |
| Electrical Durability AC-1 | 150,000 cycles |
| Electrical Durability AC-3 | 100,000 cycles |
| Mechanical Durability | 1,000,000 cycles |
| Standards | IEC/EN 60947-1, IEC/EN 60947-4-1, IEC/EN 61095, UL 508, CSA C22.2 No. 14 |
| RoHS | Compliant (EU Directive 2011/65/EU) |
| UL/CSA | Listed |
| CE Marking | Yes — Low Voltage Directive & EMC Directive |
| Condition | New Surplus Packaging |
