ABB 1SAP221200R0001 Communication Module
ABB 1SAP221200R0001 Communication Module

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

ABB

ABB 1SAP221200R0001 Communication Module

SKU: 1SAP221200R0001
(0)
$449.34
Available
Free shipping over $500
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056

ABB CI592-CS31 1SAP221200R0001 S500 CS31 Bus Interface Module

The ABB CI592-CS31 1SAP221200R0001 is S500 series CS31 bus interface combined I/O module for ABB AC500 PLC system. It integrates CS31 fieldbus communication interface together with digital and analog I/O channels for distributed automation on CS31 bus network.

Key Features

  • Integrated CS31 bus interface + multi-type I/O: 8DI / 4AI / 2AO / 8DC
  • CS31 fieldbus connection for AC500 distributed I/O system
  • Supports sensor signal acquisition and actuator control on one single module
  • Channel diagnostic LEDs and bus status indicators
  • Hot swap capability within S500 backplane system
  • DIN rail mounting, natural convection cooling
  • IP20 protection rating for cabinet installation

Technical Specifications (Official ABB Datasheet)

Order Code 1SAP221200R0001
Model CI592-CS31
Module Type CS31 Bus Interface Combined I/O Module
Integrated I/O allocation 8 Digital Input, 4 Analog Input, 2 Analog Output, 8 Configurable Digital Channel
Fieldbus Protocol CS31
Module Supply Voltage 24 V DC (20.4 ~ 28.8 V DC)
Power Consumption Max 5 W
Operating Temp (Horizontal Mount) 0 °C ~ +60 °C
Operating Temp (Vertical Mount) 0 °C ~ +40 °C, derating required
Storage / Transport Temperature -40 °C ~ +70 °C
Relative Humidity 5% to 95% non-condensing
Protection Class IP20
Mounting Standard DIN rail EN 60715
Net Dimensions (H × W × D) 76 mm × 62 mm × 67.5 mm
Net Weight 0.125 kg
HS Code 85389091

Applications

Distributed machine automation, process measurement & control, conveyor systems, packaging machinery, material handling for ABB AC500 PLC CS31 bus network.

FAQ

Q: What PLC system is CI592-CS31 for?
A: CI592-CS31 is S500 bus interface module designed for ABB AC500 PLC family.

Q: What is the communication interface?
A: CS31 fieldbus interface, with built-in mixed digital and analog I/O channels.

Q: Does it support hot swap?
A: Yes, hot-swap supported when installed on S500 backplane.

Warranty

12-month seller warranty provided by SHLY-PLC.

Model Specifications

converted_model 1SAP221200R0001
abb_type CI592-CS31
bus CS31 slave
analog_inputs 4 AI U/I/RTD
analog_outputs 2 AO U/I
digital_inputs 8 DI 24VDC
configurable_channels 8 configurable DI/DO 24VDC 0.5 A

Source: datasheet / product page
