Schneider Electric XPSDMB1132P | Safety Device

XPSDMB1132P Schneider Electric - Preventa XPS DM Magnetic Switch Monitoring Safety Module. The Schneider Electric Preventa XPS DM is a safety module for monitoring coded magnetic switches. It supports monitoring of up to 2 magnetic switches with high safety integrity level, making it suitable for guard door monitoring applications.

• Brand: Schneider Electric
• Category: Safety Modules
• Brand: Schneider Electric
• Product Range: Preventa XPS DM
• Supply Voltage: 24V DC
• Function: Coded magnetic switch monitoring (up to 2 switches)
• Outputs: 2 NO relay outputs + 2 solid state outputs
• Response Time: <=20 ms
• Thermal Current: 6A
• Safety Level: PL e / Category 4 / SIL 3
• MTTFd: 83.1 years
• Diagnostic Coverage (DC): >99%
• Indication: 3 LEDs
• Mounting: DIN rail
• Width: 22.5 mm
• Dimensions: 45 x 99 x 114 mm
• Weight: 0.25 kg
• IP Rating: IP20 (front IP40)
• Removable Terminals: Yes (P suffix)
• Certifications: UL, CSA, TUV

Ideal for monitoring coded magnetic safety switches on guard doors, access panels, and protective enclosures in industrial machinery. Provides high-integrity safety monitoring for applications requiring SIL 3 / PL e / Category 4 performance levels.
