B&R X20IF1082 | Industrial Automation Component

Category: I/O systems > X20 System > X20 interface module communication

POWERLINK for real-time Ethernet communication Integrated hub for efficient cabling Configurable ring redundancy The interface module is used for application-specific expansion of the X20 controllers.

It is equipped with a POWERLINK interface. The interface has two RJ45 sockets. Both connections lead to an integrated hub.

This makes it easy to create daisy-chain connections using POWERLINK.

Technical Specifications

Short description

• Communication module = 1x POWERLINK (V1/V2) managing or controlled node

General information

• Diagnostics
• Module status = Yes, using LED status indicator and software
• Bus function = Yes, using LED status indicator and software
• Certifications
• CE = Yes
• UKCA = Yes
• CRA (Cyber Resilience Act) = In preparation
• ATEX = Zone 2, II 3G Ex nA nC IIA T5 Gc IP20, Ta (see X20 user's manual) FTZÚ 09 ATEX 0083X
• UL = cULus E115267 Industrial control equipment
• HazLoc = cCSAus 244665 Process control equipment for hazardous locations Class I, Division 2, Groups ABCD, T5
• DNV = Temperature: B (0 to 55°C) Humidity: B (up to 100%) Vibration: B (4 g) EMC: B (bridge and open deck)
• CCS = Yes
• LR = ENV1
• KR = Yes
• ABS = Yes
• BV = EC33B Temperature: 5 - 55°C Vibration: 4 g EMC: Bridge and open deck
• KC = Yes
• B&R ID code = 0x1F1F
• Status indicators = Module status, bus function
• Power consumption = 2 W
• Additional power dissipation caused by actuators (resistive) [W] = -

Interfaces

• Transfer
• Physical layer = 100BASE-TX
• Half-duplex = Yes
• Full-duplex = No
• Autonegotiation = Yes
• Auto-MDI/MDIX = Yes
• Fieldbus = POWERLINK (V1/V2) managing or controlled node
• Type = Type 3
• Variant = 2x shielded RJ45 (hub)
• Line length = Max. 100 m between 2 stations (segment length)
• Transfer rate = 100 Mbit/s
• Hub propagation delay = 0.96 to 1 µs
• Controller = POWERLINK MAC

Electrical properties

• Electrical isolation = PLC isolated from POWERLINK (X1 and X2)

Operating conditions

• Mounting orientation
• Horizontal = Yes
• Vertical = Yes
• Installation elevation above sea level
• 0 to 2000 m = No limitation
• >2000 m = Reduction of ambient temperature by 0.5°C per 100 m
• Degree of protection per EN 60529 = IP20

Ambient conditions

• Temperature
• Operation
• Horizontal mounting orientation = -25 to 60°C
• Vertical mounting orientation = -25 to 50°C
• Derating = -
• Storage = -40 to 85°C
• Transport = -40 to 85°C
• Relative humidity
• Operation = 5 to 95%, non-condensing
• Storage = 5 to 95%, non-condensing
• Transport = 5 to 95%, non-condensing

Mechanical properties

• Slot = In the X20 PLC
