B&R X20HB8880 | Industrial Automation Component

Category: I/O systems > X20 System > X20 hub system

2x / 4x / 6x Fast Ethernet hub Modular construction Easily expandable The X20 hub is a device that can be used universally in standard Ethernet networks or POWERLINK networks.

It is suitable for 100 Mbit/s (Fast Ethernet) networks.

The bus modules expanded to the left allow connection of up to 2 hub expansion modules in addition to the hub base module.

This means that a single base device provides up to 6 hub interfaces.

Technical Specifications

Short description

• Hub = Modular X20 hub with up to 2 slots for hub expansion modules

General information

• Diagnostics
• Module status = Yes, using LED status indicator
• Bus function = Yes, using LED status indicator
• Certifications
• CE = Yes
• UKCA = Yes
• CRA (Cyber Resilience Act) = In preparation
• ATEX = Zone 2, II 3G Ex nA nC IIA T5 Gc IP20, Ta (see X20 user's manual) FTZÚ 09 ATEX 0083X
• UL = cULus E115267 Industrial control equipment
• HazLoc = cCSAus 244665 Process control equipment for hazardous locations Class I, Division 2, Groups ABCD, T5
• DNV = Temperature: B (0 to 55°C) Humidity: B (up to 100%) Vibration: B (4 g) EMC: B (bridge and open deck)
• CCS = Yes
• LR = ENV1
• KR = Yes
• ABS = Yes
• BV = EC33B Temperature: 5 - 55°C Vibration: 4 g EMC: Bridge and open deck
• KC = Yes
• Status indicators = Module status, bus function
• Power consumption = 2 W

Interfaces

• Transfer
• Physical layer = 100BASE-TX
• Half-duplex = Yes
• Full-duplex = No
• Autonegotiation = Yes
• Auto-MDI/MDIX = Yes
• Type = Hub base module
• Variant = 2x shielded RJ45
• Line length = Max. 100 m between 2 stations (segment length)
• Transfer rate = 100 Mbit/s
• Hub propagation delay = 0.96 to 1 µs

Electrical properties

• Electrical isolation = Power supply isolated from Ethernet (IF1 and IF2)

Operating conditions

• Mounting orientation
• Horizontal = Yes
• Vertical = Yes
• Installation elevation above sea level
• 0 to 2000 m = No limitation
• >2000 m = Reduction of ambient temperature by 0.5°C per 100 m
• Degree of protection per EN 60529 = IP20

Ambient conditions

• Temperature
• Operation
• Horizontal mounting orientation = -25 to 60°C
• Vertical mounting orientation = -25 to 50°C
• Derating = -
• Storage = -40 to 85°C
• Transport = -40 to 85°C
• Relative humidity
• Operation = 5 to 95%, non-condensing
• Storage = 5 to 95%, non-condensing
• Transport = 5 to 95%, non-condensing

Mechanical properties

• Pitch
• X20BB80 = 37.5 +0.2 mm
• X20BB81 = 62.5 +0.2 mm
• X20BB82 = 87.5 +0.2 mm
• Note = Order 1x terminal block X20TB12 separately. Order 1x power supply module X20PS8002 separately. Order 1x bus base X20BB8x separately.
