B&R X20CM0985 | Industrial Automation Component

Category: I/O systems > X20 System > Other functions

Energy measurement for 120 to 480 VAC Simultaneous measurement of 2 AC mains networks plus 2 additional voltages For multifunctional measurement tasks Intelligent mains synchronization unit The module has a compact size and combines a power measurement module that has special features with a synchronization unit that is able to meet all demands.

The measurement unit's 3 current inputs are suitable for both X: 1 A and X: 5 A current transformers.

Overcurrent resistance and the high resolution of the measurement unit round off its features.

For the voltage inputs, the value range can be configured between 480 VAC and 120 VAC .

The area of use includes 4-wire AC networks with a phase voltage up to 480 VAC and 3-wire systems, whereas L2 can be grounded (V-connection).

The module can also handle Aron measuring circuits.

The resulting measured values include the pure phase current; line-to-line voltage or phase voltage; the effective, reactive and apparent power parts; the mains frequency; the power factor and much more.

In addition, peak values and energy meters are stored on the module in nonvolatile memory.

Depending on the configuration, it is also possible to use a digital output as a pulse encoder for an external energy meter.

The synchronization unit doesn't just take the phasing and phase voltage into consideration; integrated intelligence also monitors the rate of change and other parameters, allowing them to influence when the synchronization output is switched.

It is also possible to monitor a generator using a large number of additional conditions.

A total of 4 voltage inputs provide substantial overall flexibility.

Monitoring functions expand the features of the module.

Dependent overcurrent monitoring is included, which utilizes the thermal capacity of the motor/generator to allow short overloads while still providing full protection.

The dependent, delayed imbalanced load monitoring used to protect three-phase generator and three-phase networks from imbalanced load can be adapted to the characteristics of different generator types using parameters while taking their special thermal time constants into account.

Technical Specifications

Short description

• I/O module = X20 energy measurement and synchronization module

General information

• Diagnostics
• Module run/error = Yes, using LED status indicator and software
• Analog inputs = Yes, using LED status indicator (measurement range of analog inputs)
• Digital outputs = Yes, using LED status indicator and software
• Power consumption
• Bus = 1.4 W
• Internal I/O = 4 W
• Certifications
• CE = Yes
• UKCA = Yes
• CRA (Cyber Resilience Act) = In preparation
• ATEX = Zone 2, II 3G Ex nA nC IIA T5 Gc IP20, Ta (see X20 user's manual) FTZÚ 09 ATEX 0083X
• UL = cULus E115267 Industrial control equipment
• HazLoc = cCSAus 244665 Process control equipment for hazardous locations Class I, Division 2, Groups ABCD, T5
• KC = Yes
• B&R ID code = 0x2433
• Status indicators = Channel status, operating state, module status
• Overvoltage category = ll
• Additional power dissipation caused by actuators (resistive) [W] = -

Digital outputs

• Switching delay
• 0 → 1 = <300 μs
• 1 → 0 = <300 μs
• Switching frequency
• Resistive load = Max. 100 Hz
• Quantity = 5
• Variant = Current-sourcing FET
• Nominal voltage = 24 VDC
• Switching voltage = 24 VDC -15% / +20%
• Nominal output current = 0.1 A
• Total nominal current = 0.5 A
• Connection type = 1-wire connections
• Output circuit = Source
• Output protection = Thermal shutdown in the event of overcurrent or short circuit
• Diagnostic status = Output monitoring with 10 ms delay
• Leakage current when the output is switched off = 5 μA
• Residual voltage = <0.3 V at 0.1 A nominal current
• Peak short-circuit current = <2 A
• Switch-on in the event of overload shutdown or short-circuit shutdown = Approx. 10 ms, depends on the module temperature
• Insulation voltage between channel and bus = 500 V eff

Relay outputs

• Switching capacity
• Min. = 10 mA / 5 VDC
• Max. = 30 W / 240 VAC
• Switching delay
• 0 → 1 = ≤10 ms
• 1 → 0 = ≤10 ms
• Service life
• Mechanical = Min. 10 x 10 6 ops.
• Electrical = Min. 60 x 10 3 ops. (NC) at 1 A Min. 30 x 10 3 ops. (NO) at 1 A
• Protective circuit
• Internal = None
• External = None
• DC = Inverse diode, RC combination or VDR
• AC = RC combination or VDR
• Insulation voltage
• Channel - Channel = 1000 VAC / 1 min
• Channel - Bus = 4000 VAC / 1 min
• Quantity = 1
• Variant = Relay / Changeover contact
• Nominal voltage = 30 VDC / 240 VAC
• Rated frequency = DC / 45 to 63 Hz
• Nominal output current = 1 A at 30 VDC / 1 A at 240 VAC
• Actuator power supply = External
• Switching voltage = Max. 60 VDC / 250 VAC
• Contact resistance = Max. 100 mΩ

Analog input voltage

• Conversion time
• 50 Hz = 20 ms
• 60 Hz = 16.67 ms
• Output format
• ±120 VAC = 1 LSB = 0x0001 = 5.707 mV
• ±480 VAC = 1 LSB = 0x0001 = 22.787 mV
• Output of digital value during overload
• Overshoot = 0x7FFF
• Undershoot = 0x8001
• Input filter
• Cutoff frequency = 10 kHz
• Slope = 60 dB
• Max. error at 25°C
• Gain = 0.09%
• Offset = 0.03%
• Channels = 8
• Input = 120 VAC / 480 VAC
• Input type = Single-ended
• Digital converter resolution = ±15-bit
• Permissible input signal = Max. 132 VAC / 528 VAC
• Conversion method = SAR
• Maximum gain drift = 0.02% per °C
• Maximum offset drift = 0.003% per °C
• Crosstalk between channels = -70 dB
• Nonlinearity = ≤0.5% at 45 to 65 Hz
• Protection against electric shock = Protective impedance per EN 61131-2
• Test voltage between channel and bus (type test) = 3700 V eff
• Output format = INT
• Input impedance in signal range = Approx. 3 MΩ
• Input protection = Overvoltage protection

Analog input current

• Conversion time
• 50 Hz = 20 ms
• 60 Hz = 16.67 ms
• Output format
• ±1 A = 1 LSB = 0x0001 = 189.903 μA
• ±5 A = 1 LSB = 0x0001 = 949.513 μA
• Output of digital value during overload
• Overshoot = 0x7FFF
• Undershoot = 0x8001
• Input filter
• Cutoff frequency = 10 kHz
• Slope = 60 dB
• Max. error at 25°C
• Gain = 0.2%
• Offset = 0.05%
• Input impedance
• Measurement range 1 A = Max. 30 mΩ
• Measurement range 5 A = Max. 10 mΩ
• Channels = 3
• Input = 1 A / 5 A AC
• Input type = Isolated current transformer according to the compensation principle with a magnet
