Model: VFD015CP43B-21
| Parameter | Value |
|---|---|
| Brand | Delta |
| Series | VFD-CP2000 Series |
| Motor Output | 1.5 kW / 2 HP (Normal Duty) |
| Input Voltage | 3-phase 380-480 VAC (-15% to +10%), 50/60 Hz |
| Input Voltage Range | 323-528 VAC |
| Output Voltage | 3-phase, proportional to input |
| Rated Output Current | 3.0 A (Normal Duty) / 4.2 A (Light Duty) |
| Max Output Frequency | 599 Hz |
| Carrier Frequency | 2-15 kHz (default 8) |
| Control Mode | V/F, SVC (Sensorless Vector Control), PM |
| Starting Torque | 150% at 0.5 Hz |
| Overload Tolerance | ND: 120% for 1 min; LD: 160% for 3 sec |
| Efficiency | 97.8% |
| Power Factor | > 0.98 |
| Built-in Brake Chopper | Yes |
| Built-in EMC Filter | Yes (version B) |
| Built-in PLC | Yes (10K steps) |
| Communication | Modbus, BACnet (built-in); ProfiBUS-DP, DeviceNet, Modbus TCP, EtherNet-IP, CANopen (optional) |
| Protection Rating | IP20 / NEMA 1 |
| Operating Temperature | -10 to 50°C |
| Dimensions | 130 x 250 x 170 mm (W x H x D) |
| Weight | 2.6 ± 0.3 kg |
| Cooling | Natural cooling |
| Certification | CE / UL / cUL |
