Model: VFD015CP43B-21
Delta CP2000 industrial VFD inverter, specially designed for HVAC, water pump and fan energy-saving speed regulation. Equipped with built-in 10K-step PLC logic control, multi-segment V/F curve and PID constant pressure control, ideal for building automation and factory fluid equipment.
| MPN: | VFD015CP43B-21 |
| Brand: | Delta Electronics |
| Product Category: | Variable Frequency Drives (VFD / Inverters) |
| Product Series: | Delta CP2000 Fan & Pump Series |
| Rated Power: | 1.5kW (2HP) |
| Input Power: | 3-phase AC 380~460V, 50/60Hz |
| Rated Output Current: | 4.2A (Light Duty) |
| Control Mode: | V/F Control, SVC Sensorless Vector, PM Motor Control |
| Built-in Function: | 10K Steps PLC, PID Constant Pressure, Flying Start, Auto Tuning |
| Communication: | Built-in Modbus RS485, Optional Profinet / CANopen / EtherNet/IP |
| I/O Terminals: | 20 Digital Input, Analog 0~10V / 4~20mA, Relay Output |
| Protection Grade: | IP20 (Cabinet Installation) |
| Dimensions: | W130 × H250 × D170mm |
| Net Weight: | 2.6kg |
| Certifications: | CE, UL, cUL, RoHS |
| Recommended Use: | HVAC systems, cooling tower fans, water supply pumps, building automation, constant pressure water control |
| Suitable Space: | Indoor electrical control cabinet |
Matches 1.5kW 3-phase AC induction & permanent magnet fan/pump motors. Supports connection with Delta DVP, AH PLC series for centralized building automation control, with stable energy-saving operation for long-term continuous working.
