MELSEC iQ-R Series R60DAI8
| Output specifications | / 8 points (8 channels) |
| Number of analog output points | 16-bit signed binary value (-32768...32767) |
| Digital input | 0...20 mA DC (external load resistance 0...600 Ω) |
| Analog output - Current | Digital input value (resolution) |
| I/O characteristics, resolution - Output range | 0...32000 (625.0 nA) |
| I/O characteristics, resolution - Current output - 0...20 mA | 0...32000 (500.0 nA) |
| I/O characteristics, resolution - Current output - 4...20 mA | -32000...32000 (350.9 nA) |
| I/O characteristics, resolution - Current output - User range setting | Within ±0.1 % |
| Accuracy (accuracy of the maximum analog output value) - Ambient temperature: 25±5 ﾟC | Within ±0.3 % |
| Accuracy (accuracy of the maximum analog output value) - Ambient temperature: 0...55 ﾟC | 80 µs/channel |
| D/A conversion speed | Protected |
| Output short protection | / Between I/O terminals and programmable controller power supply: Photocoupler Between output channels: Non-isolation Between external power supply and analog outputs: Transformer |
| Common specifications | Between I/O terminals and programmable controller power supply: 500 V AC rms for 1 minute Between external power supply and analog outputs: 500 V AC rms for 1 minute |
| Isolation method | Between I/O terminals and programmable controller power supply: 500 V DC 10 MΩ or higher |
| Dielectric withstand voltage | 24 V DC (+20/-15 %, ripple, spike 500 mVp-p or lower) |
| Insulation resistance | 0.26 A (inrush current: 5.0 A, 700 µs or lower) |
| External power supply - Voltage | 18-point terminal block (M3 screw) |
| External power supply - Current | 16 points (I/O assignment: Intelligent 16 points) |
| External interface - | 0.16 A |
| Number of occupied I/O points | 106 mm (base unit mounting side: 98 mm) |
| Internal current consumption (5 V DC) | 27.8 mm |
| External dimensions - Height | 131 mm |
| External dimensions - Width | 0.19 kg |
| General specifications | Refer to the general specifications of the CPU module or remote head module. |
