MELSEC iQ-R Series R08ENCPU
| Hardware specifications | / Stored program cyclic operation |
| Operation control method | Refresh mode (The direct access input/output is available by specifying the direct access input/output (DX, DY).) |
| I/O control mode | 0.98 ns |
| Instruction processing time - LD instruction | 1.96 ns |
| Instruction processing time - MOV instruction | 1.96 ns |
| Instruction processing time (structured text) - IF | 1.96 ns |
| Instruction processing time (structured text) - CASE | 1.96 ns |
| Instruction processing time (structured text) - FOR | 80K steps (320K bytes) |
| Memory capacity - Program capacity | 320K bytes |
| Memory capacity - SD memory card | 1188K bytes |
| Memory capacity - Device/label memory | 10K bytes |
| Memory capacity - Signal flow memory - Area for programs | 256K bytes |
| Memory capacity - Signal flow memory - Area for function blocks | 5M bytes |
| Memory capacity - Data memory | 5120K bytes |
| Memory capacity - Function memory | 1072K bytes (536K words) (including the fixed scan communication area (24K words)) |
| Memory capacity - CPU buffer memory | 2048K bytes |
| Memory capacity - Refresh memory | 380 |
| Maximum number of storable files - Program memory | 324 (with or without an extended SRAM cassette) |
| Maximum number of storable files - Device/label memory (file storage area) | 512 |
| Maximum number of storable files - Data memory | 512 |
| Maximum number of storable files - Function memory | • NZ1MEM-2GBSD: 256 • NZ1MEM-4GBSD, NZ1MEM-8GBSD, NZ1MEM-16GBSD: 32767 |
| Maximum number of storable files - SD memory card | 512 |
| Number of storable folders - Data memory | 512 |
| Number of storable folders - Function memory | • NZ1MEM-2GBSD: 256 • NZ1MEM-4GBSD, NZ1MEM-8GBSD, NZ1MEM-16GBSD: 32767 |
| Number of storable folders - SD memory card | USB2.0 High Speed (miniB)×1 |
| USB port | CPU part: 10BASE-T/100BASE-TX×1 Network part: 10BASE-T/100BASE-TX/1000BASE-T×2 |
| Ethernet port | Year, month, date, hour, minute, second, and day of week (automatic leap year adjustment) Accuracy: -1.00...+1.00 s/d at 0...55 ˚C |
| Clock function | CPU part: - Network part: 32 points (I/O assignment: Intelligent 32 points) |
| Number of occupied I/O points | Capacitor |
| Backup power - Backup method | Three minutes |
| Backup power - Backup power time | Device/label memory, clock data |
| Allowable momentary power failure time | 1.49 A |
| Internal current consumption (5 V DC) | 106 mm (base unit mounting side: 98 mm) |
| External dimensions - Height | 56 mm |
| External dimensions - Width | 110 mm |
| External dimensions - Depth | 0.40 kg |
| Weight | / Ladder diagram (LD), sequential function chart (SFC), structured text (ST), function block diagram (FBD/LD) |
| Programming specifications | Function block (FB), label programming (system/local/global) |
| Programming language | Initial execution type, scan execution type, fixed scan execution type, event execution type, standby type |
| Programming supporting function | Internal timer interrupt (I28 to I31), high-speed internal timer interrupt 1 (I49), high-speed internal timer interrupt 2 (I48), interrupt by modules, inter-module synchronous interrupt (I44) |
| Program operation - Execution type - Standard program | 252 |
| Program operation - Type of interrupt - Standard program | 128 |
| Number of executable programs - General program | 0.2...2000 ms (in 0.1 ms increments) |
| Number of FB files - FB file | 0.5...1000 ms (in 0.5 ms increments) |
| Tact performance - Constant scan | 0.05...1000 ms (in 0.05 ms increments) |
| Tact performance - Cyclic interrupt - Interrupt using the internal timer (I28...I31) | 0.05...1000 ms (in 0.05 ms increments) |
| Tact performance - Cyclic interrupt - High-speed internal timer interrupt 1 (I49) | 0.1...10.00 ms (in 0.05 ms increments) |
| Tact performance - Cyclic interrupt - High-speed internal timer interrupt 2 (I48) | 1...1000 ms (Default: 100 ms) |
| Tact performance - Cyclic interrupt - Inter-module synchronous interrupt (I44) | 0.01...100 ms (Default: 10 ms) |
| Timer performance - Low-speed timer | 0.001...1000 ms (Default: 0.001 ms) |
| Timer performance - High-speed timer | 4096 points |
| Timer performance - Long timer | 12288 points (fixed) |
| Number of I/O points | 12288 points (fixed) |
| Number of user device points - Input (X) | 12288 points (user-changeable) |
| Number of user device points - Output (Y) | 8192 points (user-changeable) |
| Number of user device points - Internal relay (M) | 8192 points (user-changeable) |
| Number of user device points - Latch relay (L) | 2048 points (user-changeable) |
| Number of user device points - Link relay (B) | 2048 points (user-changeable) |
| Number of user device points - Link special relay (SB) | 2048 points (user-changeable) |
| Number of user device points - Annunciator (F) | 0 points (user-changeable) |
| Number of user device points - Edge relay (V) | 1024 points (user-changeable) |
| Number of user device points - Step relay (S) | 1024 points (user-changeable) |
| Number of user device points - Timer device - Timer (T) | 0 points (user-changeable) |
| Number of user device points - Timer device - Long timer (LT) | 0 points (user-changeable) |
| Number of user device points - Retentive timer device - Retentive timer (ST) | 512 points (user-changeable) |
| Number of user device points - Retentive timer device - Long retentive timer (LST) | 512 points (user-changeable) |
| Number of user device points - Counter device - Counter (C) | 18432 points (user-changeable) |
| Number of user device points - Counter device - Long counter (LC) | 8192 points (user-changeable) |
| Number of user device points - Data register (D) | 2048 points (user-changeable) |
| Number of user device points - Link register (W) | 4096 points (fixed) |
| Number of user device points - Link special register (SW) | 4096 points (fixed) |
| Number of system device points - Special relay (SM) | 16 points (fixed) |
| Number of system device points - Special register (SD) | 16 points (fixed) |
| Number of system device points - Function input (FX) | 5 points × 4 words (fixed) |
| Number of system device points - Function output (FY) | 0 points (user-changeable) |
| Number of system device points - Function register (FD) | 20 points (user-changeable, up to 24 points) |
| Number of file register points - File register (R/ZR) | 2 points (user-changeable, up to 12 points) |
| Number of index register points - Index register (Z) | 8192 points (user-changeable, up to 16384 points) |
| Number of index register points - Long index register (LZ) | 1024 points (fixed) |
| Number of pointer points - Pointer (P) (global/local) | 160K points maximum |
| Number of pointer points - Interrupt pointer (I) | 160K points maximum |
| Number of link direct device points - Link input (J☐\X☐) | 640K points maximum |
| Number of link direct device points - Link output (J☐\Y☐) | 2560K points maximum |
| Number of link direct device points - Link relay (J☐\B☐) | 5120 points maximum |
| Number of link direct device points - Link register (J☐\W☐) | 5120 points maximum |
| Number of link direct device points - Link special relay (J☐\SB☐) | 268435456 points maximum |
| Number of link direct device points - Link special register (J☐\SW☐) | 268435456 points maximum |
| Number of module access device points - Intelligent function module device (U☐\G☐) | 12288 points maximum |
| Number of CPU buffer memory access device points - Buffer memory (U3E☐\G☐) | 524288 points (1048576 points maximum) |
| Number of CPU buffer memory access device points - Fixed scan communication area in the buffer memory (U3E☐\HG☐) | 15 points |
| Number of refresh data register points - Refresh data register (RD) | 320 points |
| Number of other device points - SFC block device (BL) | / CPU part: 100/10 Mbps Network part: 1 Gbps/100/10 Mbps |
| Number of other device points - SFC transition device (TR) | 1000BASE-T: Full-duplex (network part) 100BASE-TX: Full-duplex/half-duplex 10BASE-T: Full-duplex/half-duplex |
| Specifications of the built-in Ethernet function | RJ45 (AUTO MDI/MDI-X) |
| Transmission specifications - Data transmission speed | Base band |
| Transmission specifications - Interface | CPU part: Not available Network part: Available |
| Transmission specifications - Transmission method | 100 m (length between hub and node) |
| Transmission specifications - Maximum frame size | IPv4 |
| Transmission specifications - Jumbo frame | CPU part: 16 connections (connections usable on a program) Network part: 64 connections (connections usable on a program) |
| Transmission specifications - Maximum segment length | CPU part: - Network part: 5K words × 16 |
| Transmission specifications - IP version | CPU part: 5K words × 16 Network part: 5K words × 48 |
| Sending/receiving data storage memory - Number of simultaneously open connections | CPU part: - Network part: 6K words × 1 |
| Operating ambient temperature | 0...55 ˚C |
| Storage ambient temperature | -25...75 ˚C |
| Operating ambient humidity | 5...95 %RH, non-condensing |
| Storage ambient humidity | 5...95 %RH, non-condensing |
| Vibration resistance - IEC 61131-2: 2007/JIS B 3502: 2011 - Under intermittent vibration | Frequency: 5...8.4 Hz, Half amplitude: 3.5 mm Frequency: 8.4...150 Hz, Constant acceleration: 9.8 m/s 2 Sweep count: 10 times each in X, Y, and Z directions |
| Vibration resistance - IEC 61131-2: 2007/JIS B 3502: 2011 - Under continuous vibration | Frequency: 5...8.4 Hz, Half amplitude: 1.75 mm Frequency: 8.4...150 Hz, Constant acceleration: 4.9 m/s 2 |
| Shock resistance - IEC 61131-2: 2007/JIS B 3502: 2011 | Three shocks in each direction per axis, on 3 mutually perpendicular axes (total of 18 shocks) |
| Operating atmosphere | No corrosive gases, flammable gases, less conductive dust |
| Operating altitude | 0...2000 m |
| Installation location | Inside a control panel |
| Overvoltage category | II or less |
| Pollution degree | 2 or less |
