Enhanced Modbus TCP/IP Module for ControlLogix
Enhanced Modbus TCP/IP Client/Server Network Interface Module with Ethernet configuration, diagnostics, web server, and CIPconnect technology.
| Platform | Rockwell Automation ControlLogix (1756 backplane) |
| Backplane Current Load | 800 mA @ 5V DC, 3 mA @ 24V DC |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Shock | 30g operational, 50g non-operational |
| Vibration | 5 g from 10 to 150 Hz |
| Relative Humidity | 5% to 95% (non-condensing) |
| Processor Compatibility | ControlLogix processors (firmware v10+) |
| Configuration Port | RJ45 RS-232, CIPconnect Ethernet routing |
| Configuration Software | ProSoft Configuration Builder (PCB) |
| Enhanced Features | Ethernet port for config/diagnostics, web server |
| Agency Approvals | UL/cUL Class I Div 2, ATEX, CE |
| Protocol | Modbus TCP/IP (Client/Server) |
| Ethernet Port | 10/100 Base-T, RJ45, auto-crossover |
| Server Connections | 5 on Port 502, 5 on Port 2000 |
| Client Connections | 1 client, up to 100 commands |
| Data Registers | Up to 5000 registers |
