PROFIBUS DPV1 Master Module for ControlLogix
PROFIBUS DPV1 Master communication module for ControlLogix. Acts as PROFIBUS network scanner with DPV1 acyclic data support.
| Platform | Rockwell Automation ControlLogix (1756 backplane) |
| Backplane Current Load | 800 mA @ 5V DC |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Shock | 30g operational, 50g non-operational |
| Vibration | 5 g from 10 to 150 Hz |
| Relative Humidity | 5% to 95% (non-condensing) |
| Processor Compatibility | ControlLogix processors |
| Configuration Port | RJ45 RS-232 (DB-9M with supplied cable) |
| Configuration Software | ProSoft Configuration Builder (PCB) |
| Agency Approvals | UL/cUL Class I Div 2, ATEX, CE |
| Protocol | PROFIBUS DPV1 Master (IEC 61158) |
| PROFIBUS Interface | DB-9F optically isolated RS-485 |
| Max Baud Rate | 12 Mbps (all standard baud rates) |
| Max Slaves | Up to 125 with repeater |
| Cyclic Data | Up to 1536 bytes input and 1536 bytes output |
| Features | DPV1 acyclic read/write, alarm handling, Sync/Freeze, FDT/DTM support |
