Modbus TCP/IP Client/Server Module for ControlLogix
Modbus TCP/IP Client/Server Network Interface Module for ControlLogix. Single 10/100 Ethernet port with configurable client/server operation.
| Platform | Rockwell Automation ControlLogix (1756 backplane) |
| Backplane Current Load | 800 mA @ 5V DC |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Shock | 30g operational, 50g non-operational |
| Vibration | 5 g from 10 to 150 Hz |
| Relative Humidity | 5% to 95% (non-condensing) |
| Processor Compatibility | ControlLogix processors |
| Configuration Port | RJ45 RS-232 (DB-9M with supplied cable) |
| Configuration Software | ProSoft Configuration Builder (PCB) |
| Agency Approvals | UL/cUL Class I Div 2, ATEX, CE |
| Protocol | Modbus TCP/IP (Client/Server) |
| Ethernet Port | 10/100 Base-T, RJ45, auto-crossover |
| Server Connections | 5 on Port 502 (MBAP), 5 on Port 2000 (Encapsulated) |
| Client Connections | 1 client, up to 100 commands |
| Data Registers | Up to 5000 registers |
| Floating Point | Supported (Enron, Daniel) |
