DF1 Master/Slave Communication Module for ControlLogix
DF1 Master/Slave communication module for ControlLogix platform.
| Platform | Rockwell Automation ControlLogix (1756 backplane) |
| Backplane Current Load | 800 mA @ 5V DC |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Shock | 30g operational, 50g non-operational |
| Vibration | 5 g from 10 to 150 Hz |
| Relative Humidity | 5% to 95% (non-condensing) |
| Processor Compatibility | ControlLogix processors |
| Configuration Port | RJ45 RS-232 (DB-9M with supplied cable) |
| Configuration Software | ProSoft Configuration Builder (PCB) |
| Agency Approvals | UL/cUL Class I Div 2, ATEX, CE |
| Protocol | DF1 (Master/Slave) |
| Serial Ports | 2 (RS-232/422/485) |
| Baud Rate | 110 to 115.2K baud |
