Application Development Module with Ethernet for SLC
C Programmable Application Development Module with Ethernet for SLC platform. Provides one isolated serial port, one non-isolated serial port, and one Ethernet port.
| Platform | Rockwell Automation SLC (1746 backplane) |
| Backplane Current Load | 800 mA @ 5V DC |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Shock | 30g operational, 50g non-operational |
| Vibration | 5 g from 10 to 150 Hz |
| Relative Humidity | 5% to 95% (non-condensing) |
| Processor Compatibility | SLC 5/02 M0/M1 capable or newer |
| Configuration Port | RJ45 RS-232 (DB-9M with supplied cable) |
| Configuration Software | ProSoft Configuration Builder (PCB) |
| Agency Approvals | UL/cUL Class I Div 2, ATEX, CE |
| Protocol Support | Ethernet TCP/IP, Custom serial protocols |
| Serial Ports | 2 (1 isolated, 1 non-isolated) |
| Ethernet Port | 10/100 Base-T |
| Operating System | General Software DOS 6-XL |
| Memory | Up to 4000 bytes data transfer |
