Sensor Head, Wide Type, Laser Class 2 LK-H157
| Model | |
| LK-H157; Mounting mode | |
| Diffuse reflective / Specular reflective *1; Reference distance | |
| Diffuse reflective | 150 mm 5.91" Specular reflective: 147.5 mm 5.81"; Measuring range |
| Diffuse reflective | ±40 mm ±1.57" Specular reflective: -39.5 mm to +24.4 mm -1.56" to +0.96" *2; Light source |
| Type | |
| Red semiconductor laser; Wavelength | |
| 655nm; Laser class | |
| IEC 60825-1 | Class 2 FDA(CDRH)21CFR Part 1040.10: Class II; Output |
| 0.95mW; Spot diameter (at standard distance) | |
| 120 µm x 4,200 µm; Linearity | |
| ±0.02% of F.S. (F.S.= 80 mm 3.15" ) *3; Repeatability | |
| 0.25 µm *4; Sampling cycle | |
| 2.55/5/10/20/50/100/200/500/1000 µs (9 steps selectable); Temperature characteristics | |
| 0.01% of F.S. (F.S.= 80 mm 3.15" ); Environmental resistance | |
| Enclosure rating | |
| IP67; Ambient light | |
| Incandescent lamp or fluorescent lamp | 5,000 lux max.; Ambient temperature |
| 0 to +50 °C 32 to 122 °F *5; Relative humidity | |
| 35 to 85 % RH (No condensation); Vibration resistance | |
| 10 to 55 Hz, Double amplitude 1.5 mm 0.06" , 2 hours in each of the X, Y, and Z directions; Material | |
| Aluminum die-cast; Weight | |
| Approx. 300 g; *1 Use one of the following dark filters when measuring a transparent or mirror surface object | LK-H082/LK-H087: LK-F3, LK-H152/LK-H157: LK-F2 *2 Measurement range when the sampling cycle is 20 µs or more. *3 This value is obtained when the KEYENCE standard target (White diffuse workpiece or workpiece with a metal mirror surface only for the LK-H008/LK-H008W) is measured in the normal measurement mode. *4 This value is obtained when the KEYENCE standard target (White diffuse workpiece or workpiece with a metal mirror surface only for the LK-H008/LK-H008W) is measured at the reference distance with the number of averaging measurements set to 16384. The value in parentheses is a typical e x ample of a measurement with the number of averaging measurements set to 65536 and the sampling cycle to 200 µs. *5 When the ambient temperature rises to 40 °C 104 °F or more, mount this on a metal plate before use. |
LK-H157, Sensor Head, Wide Type, Laser Class 2 in LK-G5000 series by KEYENCE America.
