Sensor Head, Wide Type LK-H025
| Model | |
| LK-H025; Mounting mode | |
| Diffuse reflective; Reference distance | |
| 20mm 0.787"; Measuring range | |
| ±3 mm ±0.12" *1; Light source | |
| Type | |
| Red semiconductor laser; Wavelength | |
| 655nm; Laser class | |
| IEC 60825-1 | Class 3R FDA(CDRH)21CFR Part 1040.10: Class IIIa; Output |
| 4.8mW; Spot diameter (at standard distance) | |
| 25 µm x 1,400 µm; Linearity | |
| ±0.02%of F.S. (F.S.= 6 mm 0.24" ) *2; Repeatability | |
| 0.02 µm (0.01 µm) *3; Sampling cycle | |
| 2.55/5/10/20/50/100/200/500/1000 µs (9 steps selectable); Temperature characteristics | |
| 0.01% of F.S./°C (F.S.= 6 mm 0.24" ); Environmental resistance | |
| Enclosure rating | |
| IP67; Ambient light | |
| Incandescent lamp or fluorescent lamp | 10,000 lux max.; Ambient temperature |
| 0 to +50 °C 32 to 122 °F; Relative humidity | |
| 35 to 85 % RH (No condensation); Vibration resistance | |
| 10 to 55 Hz, Double amplitude 1.5 mm 0.06" , 2 hours in each of the X, Y, and Z directions; Material | |
| Aluminum die-cast; Weight | |
| Approx. 230 g; *1 Measurement range when the sampling cycle is 20 µs or more. *2 This value is obtained when the KEYENCE standard target (White diffuse workpiece or workpiece with a metal mirror surface only for the LK-H008/LK-H008W) is measured in the normal measurement mode. *3 This value is obtained when the KEYENCE standard target (White diffuse workpiece or workpiece with a metal mirror surface only for the LK-H008/LK-H008W) is measured at the reference distance with the number of averaging measurements set to 16384. The value in parentheses is a typical e x ample of a measurement with the number of averaging measurements set to 65536 and the sampling cycle to 200 µs. | |
LK-H025, Sensor Head, Wide Type in LK-G5000 series by KEYENCE America.
