Sensor Head Spot Type, Laser Class 3B LK-H023
| Model | |
| LK-H023; Mounting mode | |
| Diffuse reflective; Reference distance | |
| 20mm 0.787"; Measuring range | |
| ±3 mm ±0.12" *1; Light source | |
| Type | |
| Red semiconductor laser; Wavelength | |
| 690nm; Laser class | |
| Class 3B; Output | |
| 50mW; Spot diameter (at standard distance) | |
| ø25 µm; Linearity | |
| ±0.02% of F.S. (F.S. = 6 mm 0.24" ) *2; Repeatability | |
| 0.02 µm (0.01 µm) *3; Sampling cycle | |
| 2.55, 5, 10, 20, 50, 100, 200, 500, 1,000 µs (selectable from 9 levels); Temperature characteristics | |
| 0.01% of F.S./°C (F.S. = 6 mm 0.24" ); Environmental resistance | |
| Enclosure rating | |
| IP67; Ambient light | |
| Incandescent lamp or fluorescent lamp | 10,000 lux or less; Ambient temperature |
| 0 to +45 °C 32 to 113 °F *4; Relative humidity | |
| 35 to 85 % RH (No condensation); Vibration resistance | |
| 10 to 55 Hz, Double amplitude 1.5 mm 0.06" , 2 hours in each of the X, Y, and Z directions; Material | |
| Aluminum die-cast; Weight | |
| Approx. 230 g (including the cable); *1 For details on the measurement range, see page 1-12 (when the sampling cycle is between 2.55 and 10 µs). *2 This value was taken when measuring a KEYENCE standard target (white diffuse object) in standard mode. *3 These values were taken when measuring a KEYENCE standard target (white diffuse object) at a reference distance and with the number of averaging measurements set to 16, 384. The value in the parentheses is a typical e x ample when measured with 65, 536 averaging measurements. *4 If the ambient usage temperature is 40 °C 104 °F or higher, the LK-H023/H028 must be used while attached to a metal plate. | |
LK-H023, Sensor Head Spot Type, Laser Class 3B in LK-G5000 series by KEYENCE America.
