Sensor Head, Wide Type LK-H008W
| Model | |
| LK-H008W; Mounting mode | |
| Specular reflective; Reference distance | |
| 8 mm 0.315"; Measuring range | |
| ±0.5 mm ±0.02" *1; Light source | |
| Type | |
| Red semiconductor laser; Wavelength | |
| 655nm; Laser class | |
| IEC 60825-1 | Class 1 FDA(CDRH)21CFR Part 1040.10: Class II; Output |
| 0.3mW; Spot diameter (at standard distance) | |
| 20 µm x 550 µm; Linearity | |
| ±0.05% of F.S. (F.S.= 1 mm 0.04" ) *2; Repeatability | |
| 0.005 µm (0.001 µm) *3; Sampling cycle | |
| 2.55/5/10/20/50/100/200/500/1000 µs (9 steps selectable); Temperature characteristics | |
| 0.02% of F.S./°C (F.S.=1 mm 0.04" ); Environmental resistance | |
| Enclosure rating | |
| IP67; Ambient light | |
| Incandescent lamp or fluorescent lamp | 10,000 lux max.; Ambient temperature |
| 0 to +50 °C 32 to 122 °F *4; Relative humidity | |
| 35 to 85 % RH (No condensation); Vibration resistance | |
| 10 to 55 Hz, Double amplitude 1.5 mm 0.06" , 2 hours in each of the X, Y, and Z directions; Material | |
| Aluminum die-cast; Weight | |
| Approx. 240 g; *1 Measurement range when the sampling cycle is 20 µs or more. *2 This value is obtained when the KEYENCE standard target (White diffuse workpiece or workpiece with a metal mirror surface only for the LK-H008/LK-H008W) is measured in the normal measurement mode. *3 This value is obtained when the KEYENCE standard target (White diffuse workpiece or workpiece with a metal mirror surface only for the LK-H008/LK-H008W) is measured at the reference distance with the number of averaging measurements set to 16384. The value in parentheses is a typical e x ample of a measurement with the number of averaging measurements set to 65536 and the sampling cycle to 200 µs. *4 When the ambient temperature rises to 40 °C 104 °F or more, mount this on a metal plate before use. | |
LK-H008W, Sensor Head, Wide Type in LK-G5000 series by KEYENCE America.
