Sensor Head, Wide Type LK-G85
| Model | |
| LK-G85; Reference distance | |
| 80 mm 3.15" (Diffuse reflection),75.2 mm 2.96" (Specular reflection); Measuring range | |
| ±15 mm ±0.59" (Diffuse reflection),±14 mm ±0.55" (Specular reflection); Light source | |
| Type | |
| Red semiconductor laser; Wavelength | |
| 655nm (Visible light), Class 3R laser product (JIS C6802); Laser Class | |
| Class 3R (IEC 60825-1), Class IIIa (FDA CDRH Part 1040.10); Output | |
| 4.8 mW; Spot diameter (at reference distance) | |
| Approx. 70 x 1100 µm 0.02756" x 0.0433"; Linearity | |
| ±0.05% of F.S. (F.S.= ±15 mm ±0.59" ) *1; Repeatability | |
| 0.2 µm 0.000008" *2; Sampling frequency | |
| 20/50/100/200/500/1,000 µs (Selectable from 6 levels); LED display | |
| Near the center of the measurement | Green lights Within the measurement area: Orange lights Outside the measurement area: Orange flashing; Temperature characteristics |
| 0.01% of F.S./°C (F.S.= ±15 mm ±0.59" ); Environmental resistance | |
| Enclosure rating | |
| IP67 (IEC60529); Ambient light | |
| Incandescent lamp or Fluorescent lamp | 10,000 lux max.; Ambient temperature |
| 0 to +50 °C 32 to 122 °F; Relative humidity | |
| 35 to 85 % RH (No condensation); Vibration resistance | |
| 10 to 55 Hz, Double amplitude 1.5 mm 0.06" , 2 hours in each of the X, Y, and Z directions; Material | |
| Aluminum die-cast; Weight | |
| Approx. 380 g (including the cable); *1 This value was taken when measuring a KEYENCE standard target (ceramic) in standard mode. *2 These values were taken when measuring a KEYENCE standard target (SUS) at a reference distance and with the number of averaging measurements set to 4,096 | |
LK-G85, Sensor Head, Wide Type in LK-G3000 series by KEYENCE America.
