Sensor Head: Ultra Long Distance, Small spot LK-G502
| Model | |
| LK-G502; Reference distance | |
| Diffused reflection | 500 mm 19.69" , Specular reflection: 497.5 mm 19.59"; Measuring range |
| Diffused reflection | -250 to +500 mm -9.84" to 19.69" , Specular reflection: -249 to +498 mm -9.80" to 19.61" *1 *2; Light source |
| Type | |
| Red semiconductor laser; Wavelength | |
| 655 nm (visible light); Laser Class | |
| Class II (FDA CDRH 21CFR PART1040.10); Output | |
| 0.95 mW; Spot diameter (at reference distance) | |
| Approx. ø300 µm ø0.0118"; Linearity | |
| ±0.05 % of F.S. (±250 µm ±0.0098" ) *3 *4 -250 to +250 mm -9.84" to +9.84" High-accuracy range | ±0.02 % of F.S. (±100 µm ±0.0039" ) -250 to -50 mm -9.84" to -1.97" Long range: ±0.1 % of F.S. (±500 µm ±0.0197" ) -250 to +500 mm -9.84" to +19.69" (F.S. = ±250 mm ±9.84" ) *5; Repeatability |
| 2 µm 0.000079" *6; Sampling frequency | |
| 20 / 50 / 100 / 200 / 500 / 1,000 µs (Selectable from 6 levels); LED display | |
| Near the center of the measurement | Green lights Within the measurement area: Orange lights Outside the measurement area: Orange flashing; Temperature characteristics |
| 0.01 % of F.S./°C (F.S.= ±250 mm ±9.84" ); Environmental resistance | |
| Enclosure rating | |
| IP67 (IEC60529); Ambient light | |
| Incandescent lamp or Fluorescent lamp | 5,000 lux max.; Ambient temperature |
| 0 to +50 °C 32 to 122 °F; Relative humidity | |
| 35 to 85 % RH (No condensation); Vibration resistance | |
| 10 to 55 Hz, Double amplitude 1.5 mm 0.06" , 2 hours in each of the X, Y, and Z directions; Material | |
| Aluminum die-cast; Weight | |
| Approx. 380 g (including the cable); *1 The range is obtained by measuring KEYENCE's standard target (ceramic). *2 When the sampling rate is 20 µs, the range becomes -230 mm -9.06" (NEAR side) to -250 mm -9.84" (NEAR side) for Diffused reflection. When the sampling rate is 20 µs, the range becomes -230 mm -9.06" (NEAR side) to -249 mm -9.80" (NEAR side) for specular reflection. When the sampling rate is 50 µs, the range becomes -125 mm -4.92" (NEAR side) to -250 mm -9.84" (NEAR side) for Diffused reflection. When the sampling rate is 50 µs, the range becomes -125 mm -4.92" (NEAR side) to -249 mm -9.80" (NEAR side) for specular reflection. *3 All are calculated at F.S. = ±250 mm ±9.84" . *4 "High accuracy range" and "long range" refer to the linearity when those ranges are used. *5 The range is obtained by measuring KEYENCE's standard target (ceramic) with the Standard mode. *6 The range is obtained by measuring KEYENCE's standard (SUS) with 4,096 times of averaging at the reference distance. | |
LK-G502, Sensor Head: Ultra Long Distance, Small spot in LK-G3000 series by KEYENCE America.
