Main controller: Built-in type, PNP LK-G5001PV
| Model | |
| LK-G5001PV *1 *2; Separate type | |
| LK-G5001P/LK-HD500; Type | |
| Main controller; Sensor head compatibility | |
| Compatible; No. of connectable sensor heads | |
| 2; Display | |
| Minimum display unit | |
| LK-HD500 | 0.001 µm; Display range |
| LK-HD500 | ±999.999 µm to ±9,999.99 mm (7 settings selectable); Display cycle |
| LK-HD500 | Approx 10 times/sec.; Display interface |
| Display port | |
| Either the display unit (LK-HD500) or dedicated touch panel (LK-HD1001) can be connected; LED indicator | |
| LASER ON; Terminal block | |
| Analog output voltage | |
| ±10 V output, Output impedance | 100 Ω; Analog current output |
| 4 to 20 mA, Maximum load resistance | 350 Ω; No. of analog outputs |
| 2; TIMING 1 input | |
| Voltage input *3; RESET 1 input; Auto-zero 1 input; Laser control input | |
| Voltage input *4; Laser remote input | |
| Non-voltage input; Alarm output | |
| PNP open-collector output; General comparator output; Expansion connector | |
| TIMING input | |
| Voltage input; RESET input; Auto-zero input; Program switching input; Binary selection input; Alarm output | |
| PNP open-collector output; Comparator output; Binary output; RS-232C interface | |
| Baud rate | 9,600 to 115,200 bps Data length: 8 bits, Stop bit length: 1 bit, Parity: None/even/odd; USB interface |
| USB 2.0 Hi-Speed compliant *5; Ethernet interface | |
| 100Base-TX/10Base-T *6; EtherNet/IP™interface | |
| Cyclic communication (implicit messaging) Message communication (explicit messaging) | UCMM and Class3 Number of connections: 32 Complies with conformance test version CT14 *7; PLC-Link |
| The following PLCs are supported | Mitsubishi Electric: MELSEC iQ-R Series, iQ-F Series, Q Series, L Series, FX Series EtherNet/IP™, CC-Link, and DeviceNet® cannot be used in conjunction with PLC-Link; Head expansion unit connector |
| Up to 10 head expansion units can be connected to one main controller; Expansion unit connector | |
| Either of the CC-Link unit (LK-CC100) or DeviceNet® unit (LK-DN100) can be connected; Power supply | |
| Power supply voltage | |
| 24 VDC ±10 %; Maximum current consumption | |
| 0.6 A or less with 1 head/3.5 A or less with 12 heads; Environmental resistance | |
| Ambient temperature | |
| When one or less head expansion unit is connected | 0 to +50 °C 32 to 122 °F . When two or more head expansion units are connected: 0 to +40 °C 32 to 104 °F .; Relative humidity |
| 35 to 85 % RH (No condensation); Weight | |
| Approx. 600 g; *1 PNP open-collector output rating | 50 mA max. (30 V max.), Residual voltage: 0.5 V max. Voltage input rating: Maximum input rating: 26.4 V, ON voltage: 10.2 V, OFF current: 0.6 mA *2 Part of the input/output circuit of the LK-G5000 Series is internally common. Be careful that no potential difference is generated between the internally common terminals due to the potential difference between the cables/external devices. For details, refer to "Precautions on wiring" in the User's Manual. *3 This input is applied to all of the synchronized OUT. *4 When the laser class 3B sensor head is connected, a key-operated switch must be used for the input to this terminal. The laser is emitted only when the key-operated switch is set to the ON position. (Select a key which can be removed only when it is set to the OFF position.) When the laser class 2/3R sensor head is connected, the laser turns on when this terminal is opened and turns off when it is short-circuited. *5 When a PC supporting USB 1.1 or USB 2.0 full speed is connected, the data refresh cycle and other operations may slow down. *6 Use the Ethernet interface only for direct connections with a PC or for local network connections with a PC or LK-G5000 Series units. *7 The EtherNet/IP™ interface cannot be used when a CC-Link unit or a DeviceNet® unit is installed. EtherNet/IP™ is supported by the latest controllers. For details on which controllers support EtherNet/IP™ , contact your nearest KEYENCE office. |
LK-G5001PV, Main controller: Built-in type, PNP in LK-G5000 series by KEYENCE America.
