Sensor Head: Long Distance, Wide beam LK-G157
| Model | |
| LK-G157; Reference distance | |
| Diffused reflection | 150 mm 5.91" , Specular reflection: 147.5 mm 5.81" (Specular reflection); Measuring range |
| Diffused reflection | ±40 mm ±1.57" , Specular reflection: ±39 mm ±1.54" *1 *2; Light source |
| Type | |
| Red semiconductor laser; Wavelength | |
| 655 nm (visible light); Laser Class | |
| Class II (FDA CDRH 21CFR PART1040.10); Output | |
| 0.95 mW; Spot diameter (at reference distance) | |
| Approx. 120 x 1,700 µm 0.0047" x 0.0669"; Linearity | |
| ±0.05 % of F.S. (F.S.= ±40 mm ±1.57" ) *3; Repeatability | |
| 0.5 µm 0.000020" *4; Sampling frequency | |
| 20 / 50 / 100 / 200 / 500 / 1,000 µs (Selectable from 6 levels); LED display | |
| Near the center of the measurement | Green lights Within the measurement area: Orange lights Outside the measurement area: Orange flashing; Temperature characteristics |
| 0.01 % of F.S./°C (F.S.= ±40 mm ±1.57" ); Environmental resistance | |
| Enclosure rating | |
| IP67 (IEC60529); Ambient light | |
| Incandescent lamp or Fluorescent lamp | 5,000 lux max.; Ambient temperature |
| 0 to +50 °C 32 to 122 °F; Relative humidity | |
| 35 to 85 % RH (No condensation); Vibration resistance | |
| 10 to 55 Hz, Double amplitude 1.5 mm 0.06" , 2 hours in each of the X, Y, and Z directions; Material | |
| Aluminum die-cast; Weight | |
| Approx. 290 g (including the cable); *1 The range is obtained by measuring KEYENCE's standard target (ceramic). *2 When the sampling rate is 20 µs, the range becomes -9 -0.35" (NEAR side) to -15 mm -0.59" (NEAR side) for Diffused reflection, and -8.7 -0.34" (NEAR side) to -14 mm -0.55" (NEAR side) for specular reflection. *3 The range is obtained by measuring KEYENCE's standard target (ceramic) with the Standard mode. *4 The range is obtained by measuring KEYENCE's standard (SUS) with 4,096 times of averaging at the reference distance. | |
LK-G157, Sensor Head: Long Distance, Wide beam in LK-G3000 series by KEYENCE America.
