Beckhoff IE1001 | Beckhoff Fieldbus Box And Io Link Box

IE1001 | Extension Box, 8-channel digital input, 24 V DC, 3 ms, M8

The IE1001 digital input module acquires the binary control signals from the process level and transmits them to the higher-level automation unit. The ...

Technical Specifications

IE1001 Number of inputs 8 Input connections M8, screw type Nominal input voltage 24 V DC (-15%/+20%) Input filter 3 ms Signal voltage “0” -3…+5 V (EN 61131-2, type 2) Signal voltage “1” 11…30 V (EN 61131-2, type 2) Input current typ. 6 mA (EN 61131-2, type 2) Sensor supply from control voltage, max. 0.5 A, short-circuit proof in total Power supply connection feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded Bit width in the process image 8 inputs Current consumption from U S (without sensor current) 25 mA Electrical isolation channels/control voltage: no, between the channels: no, control voltage/fieldbus: yes, via IP-Link Operating temperature 0…55°C Storage temperature -25…+85°C Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27 EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4 Protect. rating/installation pos

Availability: regular delivery
