Schneider Electric HMIRSPFXR6702 | Industrial Automation Component

HMIRSPFXR6702 Schneider Electric - Harmony iPC Industrial Rack PC 4U Performance (SSD, Redundant Power). High-performance 4U industrial rack PC with SSD storage and redundant power supply, powered by Intel Xeon quad-core processor for demanding industrial visualization and control applications.

• Brand: Schneider Electric
• Category: Industrial PC / Rack PC
• Range: Harmony iPC
• Product Type: Industrial rack PC
• Device: Rack PC 4U Performance
• Processor: Intel Xeon quad-core 1225, 3.1 GHz, L3 cache 8 MB
• Memory: 4 GB DDR3 RAM (default), up to 32 GB DDR3 (4 slots)
• Storage: 128 GB internal SSD (hot swap), 1x internal SATA3 slot, 4x hot swap trays (SATA2)
• Optical Drive: DVD-RW
• Video Controller: Intel HD Graphics 2500
• Display Resolution: 2048 x 1536 pixels
• Expansion Slots: 3x PCI, 4x PCI Express 16x
• Connections: 1x VGA, 1x DVI, 2x USB 3.0, 4x USB 2.0, 1x COM1 RS232, 4x COM1 optional, 2x Ethernet RJ45 (10/100/1000 Mbit/s), Audio in/out
• Operating System: Windows 7 64-bit Ultimate (multi-language)
• Supply Voltage: 100 to 240 V AC (redundant power supply)
• Power Consumption: 500 W
• Power Supply Type: Redundant
• Mounting: 19-inch rack
• Dimensions (W x H x D): 482 x 172.7 x 601.4 mm (19.0 x 6.8 x 23.7 in)
• Weight: 20.8 kg (45.9 lb)
• IP Protection: IP40
• Operating Temperature: 0 to 40 degrees C (32 to 104 degrees F)
• Storage Temperature: -20 to 60 degrees C (-4 to 140 degrees F)
• Relative Humidity: 10 to 85% non-condensing
• Watchdog Timer: 1 to 255 ms
• Cooling: 2 fans with speed control
• Standards: EN 60950-1, EN 61000-6-2, EN 61000-6-4, UL 60950-1, CSA 22-2 No 60950-1-07, FCC Part 15
• Certifications: CE, CCC, EAC, CULus

The HMIRSPFXR6702 industrial rack PC with redundant power supply and SSD storage is designed for high-availability industrial visualization, SCADA, and machine control applications where system uptime is critical.
