Schneider Electric HMIPSPS752D1X01 | Industrial Automation Component

HMIPSPS752D1X01 Schneider Electric - Easy Harmony Panel PC Performance - 15.6 inch Widescreen. High-performance 15.6-inch widescreen panel PC with Intel Core i5 processor, single-touch resistive screen, and pre-installed EcoStruxure Machine SCADA Expert software for industrial automation applications.

• Brand: Schneider Electric
• Category: Industrial PC / Panel PC
• Range: Harmony iPC (Easy Harmony)
• Product Type: Panel PC (Performance type)
• Display Size: 15.6 inch widescreen
• Display Resolution: 1366 x 768 pixels (FWXGA)
• Display Colours: 16 million colours
• Display Type: LED backlight TFT LCD
• Brightness: 400 cd/m2 (adjustable)
• Touch Panel: Single touch resistive
• Backlight Lifespan: More than 50,000 hours at 25 degrees C
• Processor: Intel Core i5-6200U (2.3 GHz)
• Memory: 8 GB DDR4 (not expandable)
• Storage: 128 GB mSATA SSD (BiCS3 3D flash)
• Expansion: 1x 2.5-inch SATA slot, 1x M.2 slot (mSATA/NVMe SSD), 1x mini PCIe (mSATA)
• Operating System: Windows 10 IoT Enterprise LTSB (64-bit, multi-language)
• Connections: 2x COM (RS232/RS422/RS485), 4x USB 3.0, 2x RJ45 Ethernet (10/100/1000 Mbps)
• Supply Voltage: 12 to 24 V DC (-15% / +20%)
• Power Connector: 2-pin power terminal
• Dimensions: 400 x 254 x 50.5 mm (15.8 x 10.0 x 1.98 in)
• Cut-out Dimensions: 390 x 244 mm (15.4 x 9.6 in)
• Weight: 3.8 kg (8.38 lb)
• IP Protection: IP65 front panel
• Anti-scratch Hardness: 3H
• Operating Temperature: 0 to 55 degrees C (32 to 131 degrees F) with SSD
• Storage Temperature: -20 to 60 degrees C (-4 to 140 degrees F)
• Vibration Resistance: 1g, 3-150 Hz (with SSD)
• Software: EcoStruxure Machine SCADA Expert (pre-installed)
• Mounting: Panel mounting (8 fastener screws) or VESA 75x75 mm

The HMIPSPS752D1X01 panel PC is designed for industrial automation applications from single machine control to plant supervision. Ideal for packaging, pharmaceutical, food and beverage, electronics, water and wastewater, and transportation industries.
