HMIPSOS752D1W01 Schneider Electric - Easy Harmony Panel PC Optimized - 15.6 inch Widescreen. Cost-effective 15.6-inch widescreen panel PC with Intel Celeron processor, single-touch resistive screen, and pre-installed EcoStruxure Machine SCADA Expert software for industrial automation applications.

• Brand: Schneider Electric
• Category: Industrial PC / Panel PC
• Range: Harmony iPC (Easy Harmony)
• Product Type: Panel PC (Optimized type)
• Display Size: 15.6 inch widescreen
• Display Resolution: 1366 x 768 pixels (FWXGA)
• Display Colours: 16 million colours
• Display Type: LED backlight TFT LCD
• Brightness: 400 cd/m2 (adjustable)
• Touch Panel: Single touch resistive
• Backlight Lifespan: More than 50,000 hours at 25 degrees C
• Processor: Intel Celeron 3855U (1.6 GHz)
• Memory: 4 GB DDR4
• Storage: 128 GB mSATA SSD
• Expansion: 1x 2.5-inch SATA slot, 1x M.2 slot (mSATA/NVMe SSD), 1x mini PCIe (mSATA)
• Operating System: Windows 10 IoT Enterprise LTSB (64-bit, multi-language)
• Connections: 2x COM (RS232/RS422/RS485), 4x USB 3.0, 2x RJ45 Ethernet (10/100/1000 Mbps)
• Supply Voltage: 12 to 24 V DC (-15% / +20%)
• Power Connector: 2-pin power terminal
• Dimensions: 400 x 254 x 50.5 mm (15.8 x 10.0 x 1.98 in)
• Cut-out Dimensions: 390 x 244 mm (15.4 x 9.6 in)
• Weight: 3.8 kg (8.38 lb)
• IP Protection: IP65 front panel
• Anti-scratch Hardness: 3H
• Operating Temperature: 0 to 55 degrees C (32 to 131 degrees F) with SSD
• Storage Temperature: -20 to 60 degrees C (-4 to 140 degrees F)
• Vibration Resistance: 1g, 3-150 Hz (with SSD)
• Software: EcoStruxure Machine SCADA Expert (pre-installed)
• Mounting: Panel mounting (8 fastener screws) or VESA 75x75 mm

The HMIPSOS752D1W01 panel PC is designed for cost-effective industrial automation applications from single machine control to lite supervision. Ideal for packaging, pharmaceutical, food and beverage, electronics, water and wastewater, and transportation industries.
