HMIPEP0952D1001 Schneider Electric - Harmony iPC Enclosed PC Performance - 18.5 inch Multi-touch. 18.5-inch multi-touch enclosed industrial PC with Intel Core i3 processor, fanless design, and IP65 all-sides protection for harsh industrial environments.

• Brand: Schneider Electric
• Category: Industrial PC / Enclosed PC
• Range: Harmony iPC (Magelis iPC)
• Product Type: Multi-touch screen, Enclosed PC Performance
• Processor: Intel Core i3 4010U 1.7 GHz
• Memory: 8 GB RAM DDR3 internal
• Storage: 1x Internal SATA HDD/SSD slot, 1x mini PCI Express full-size
• Display Size: 18.5 inch widescreen
• Display Type: Colour TFT LCD with LED backlight
• Display Resolution: 1366 x 768 pixels (WXGA)
• Display Colours: 16,777,216 colours
• Luminance: 300 cd/m2
• Touch Panel: Multi-touch projected capacitive technology (PCT), 5 points
• Backlight Lifespan: 50,000 hours
• View Angle: 160 x 170 degrees (H x V)
• Cooling: Fanless, passive
• Watchdog Timer: 1 to 255 ms
• Connections: 1x RS232 (M12 male, up to 115.2 kbits/s), 1x USB 2.0 Type A (M12 female), 2x Ethernet (M12 female, 10/100/1000 Mbit/s)
• Supply Voltage: 24 V DC (+/- 20%)
• Power Consumption: 28 to 60 W
• Mechanical Robustness: Anti-scratch hardness 7H
• Dimensions (W x H x D): 488 x 309 x 65 mm (19.21 x 12.17 x 2.56 in)
• Weight: 8 kg (17.64 lb)
• IP Protection: IP65 all sides
• Operating Temperature: 0 to 55 degrees C (SSD), 0 to 45 degrees C (HDD)
• Storage Temperature: -20 to 60 degrees C (-4 to 140 degrees F)
• Relative Humidity: 10 to 95% non-condensing
• Operating Altitude: Up to 2000 m (6561.68 ft)
• Standards: CISPR 11, CSA C22.2 No 60950, FCC Part 15 Class A, IEC 60950, IEC 61000-6-2, IEC 61000-6-4, UL 60950
• Certifications: CE, C-tick, AS/NZS, CCC, EAC, RCM
• Software: EcoStruxure Secure Connect Advisor, EcoStruxure Operator Terminal Expert, EcoStruxure Machine SCADA Expert, Vijeo Citect

The HMIPEP0952D1001 enclosed PC is designed for harsh industrial environments requiring full IP65 protection. Ideal for food and beverage, pharmaceutical, and outdoor applications where water and dust resistance is critical. Supports multi-touch operation even with water on screen.
