Schneider Electric GV2-ME04C | Industrial Automation Component

GV2-ME04C Schneider Electric - TeSys GV2ME Motor Protection Circuit Breaker. TeSys GV2ME series 3-pole thermal-magnetic motor protection circuit breaker rated for 0.4-0.63A. Designed for low-current motor protection with push-button control and screw clamp terminals. Part of the Schneider Electric TeSys GV2 range.

• Brand: Schneider Electric
• Category: Motor Protection Circuit Breaker
• Series: TeSys GV2
• Product Type: Motor protection circuit breaker
• Number of Poles: 3
• Rated Current: 0.63 A
• Thermal Trip Range: 0.4 - 0.63 A
• Trip Unit Technology: Thermal-magnetic
• Control Type: Push-button
• Rated Voltage: 690 V AC 50/60 Hz
• Insulation Voltage: 690 V AC
• Impulse Withstand Voltage: 6 kV
• Breaking Capacity at 230V: 100 kA
• Breaking Capacity at 400V: 100 kA
• Breaking Capacity at 690V: 100 kA
• Motor Power at 400V: 0.12 kW
• Terminal Type: Screw clamp
• Mounting: DIN rail or panel mount
• Protection Rating: IP20

Suitable for protecting small motors in industrial automation, fan control, pump protection, and low-power machinery applications. Provides overload and short circuit protection for motors with low current ratings.
