MELSEC-F Series FX3U-ENET-L
| Applicable PLC | FX3U (Ver. 2.21 or more), FX3UC (Ver. 2.21 or more) *Up to one module can be connected to the main unit. [Connecting to the connector-type PLC] The FX2NC-CNV-IF or FX3UC-1PS-5V is required to connect the FX3UC. |
| Number of occupied I/O points | 8 points (Taken from either the input or output points of the PLC.) |
| Mass (weight) | 0.3 kg |
| Transmission specifications - Data transmission speed | 100 Mbps/10 Mbps |
| Transmission specifications - Communication mode | Full-duplex/Half-duplex |
| Transmission specifications - Transmission method | Base band |
| Transmission specifications - Maximum segment length | 100 m (Length between the Hub and node.) |
| Transmission specifications - Maximum number of nodes/connection - 100 Mbps | Cascade connection Maximum 2 stages |
| Transmission specifications - Maximum number of nodes/connection - 10 Mbps | Cascade connection Maximum 4 stages |
| Transmission data storage memory - Number of simultaneously open connections allowed | 4 connections Fixed buffer communication: up to 2 connections (C1 and C2) MELSOFT connection + MC protocol: up to 2 connections (C3 and C4) |
| Transmission data storage memory - Fixed buffer | 1023 word × 2 |
| Transmission data storage memory - E-mail (Attached file) | 2048 word × 1 |
| Transmission data storage memory - E-mail (Main text) | 256 word × 1 |
| E-mail Transmission specifications (Transmission data) - Data size (Attached file) | 2048 word × 1 |
| E-mail Transmission specifications (Transmission data) - Data size (Main text) | 256 word × 1 |
| E-mail Transmission specifications (Transmission data) - Data transfer method | When sending: Sends either a file as attachment or main text (select one). |
| E-mail Transmission specifications (Transmission data) - Subject | US-ASCII format or ISO-2022-JP (Base64) |
| E-mail Transmission specifications (Transmission data) - Attached file format | MIME format |
| E-mail Transmission specifications (Transmission data) - MIME | Version 1.0 |
| E-mail Transmission specifications (Transmission data) - Data of attached file format | Binary/ASCII/CSV can be selected. File name: XXXX.bin (binary), XXXX.asc (ASCII), XXXX.csv (CSV) (CSV: Comma Separated Value) |
| E-mail Transmission specifications (Transmission data) - Division of attached file | Cannot be divided (only one file can be sent) |
| E-mail Transmission specifications (Transmission data) - When sending (encode) | Subject: Base64/7 bits Main text: 7 bits Attached file: Base64 |
| E-mail Transmission specifications (Transmission data) - Encryption | No |
| E-mail Transmission specifications (Transmission data) - Compression | No |
| E-mail Transmission specifications (Transmission data) - Communication with mail server (SMTP) - Port number | 1 to 65535 SMTP: 25 (initial) SMTP-AUTH: 587 |
| E-mail Transmission specifications (Transmission data) - Operation check mailer | Microsoft (R) Corporation Outlook (R) Express 6.0 |
| Power supply specifications | / 24 V DC +20% -15% Ripple Voltage (P-P) 5% or less |
| Power supply - | Operation can be continued upon occurrence of instantaneous power failure for 1 ms or less. |
| Allowable instantaneous power failure time | 24 V DC External power supply: 240 mA |
| Ambient temperature | 0 to 55°C (32 to 131°F) when operating and -25 to 75°C (-13 to 167°F) when stored |
| Ambient humidity | 5 to 95%RH (no condensation) when operating |
| Vibration resistance - Installed on DIN rail - Frequency: 10 to 57 Hz | Half amplitude: 0.035 mm Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Vibration resistance - Installed on DIN rail - Frequency: 57 to 150 Hz | Acceleration: 4.9 m/s 2 Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Vibration resistance - Direct installing - Frequency: 10 to 57 Hz | Half amplitude: 0.075 mm Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Vibration resistance - Direct installing - Frequency: 57 to 150 Hz | Acceleration: 9.8 m/s 2 Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Shock resistance | 147 m/s 2 Acceleration, Action time: 11 ms, 3 times by half-sine pulse in each direction X, Y, and Z |
| Noise resistance | By noise simulator at noise voltage of 1,000 Vp-p, noise width of 1 μs, rise time of 1 ns and period of 30 to 100 Hz |
| Dielectric withstand voltage | Between batch of all terminals and ground terminal: 500 V AC for 1 min |
| Insulation resistance | Between batch of all terminals and ground terminal: 5 MΩ or higher by 500 V DC insulation resistance tester |
| Working atmosphere | Free from corrosive or flammable gas and excessive conductive dusts |
| Working altitude | 2000 m or less Do not use the PLC under pressure higher than the atmospheric pressure. Doing so may damage the PLC. |
FX3U (Ver. 2.21 or more), FX3UC (Ver. 2.21 or more) *Up to one module can be connected to the main unit. [Connecting to the connector-type PLC] The FX2NC-CNV-IF or FX3UC-1PS-5V is required to connect
