MELSEC-F Series FX3U-4LC
| Applicable PLC | FX5U, FX5UC, FX3U (V2.20 and later), FX3UC (V2.20 or later) [Connecting to the FX5U, FX5UC CPU module] FX5-CNV-BUS or FX5-CNV-BUSC is required to connect to the FX5U/FX5UC CPU module. Select one of the modules according to the system configuration. [Connecting to the connector-type PLC] The FX2NC-CN |
| Number of occupied I/O points | 8 points (Taken from either the input or output points of the PLC.) |
| Mass (weight) | Approx. 0.4 kg |
| Temperature sensor/Temperature control - No. of input points | 4 points |
| Temperature sensor/Temperature control - Input type - Thermocouple | K, J, R, S, E, T, B, N (JIS C 1602-1995), PLII, W5Re/W26Re, U, L |
| Temperature sensor/Temperature control - Input type - Resistance temperature detector | 3-wire Pt100 JIS C 1604-1997 3-wire JPt100 JIS C 1604-1981 2-wire or 3-wire Pt1000 JIS C 1604-1997 |
| Temperature sensor/Temperature control - Input type - Micro voltage input | 0 to 10 mV DC, 0 to 100 mV DC A different input can be selected for each channel. |
| Temperature sensor/Temperature control - Measurement precision | Ambient temperature: 25°C±5°C When K type thermocouple Input range 500℃ or more, ±(0.3% of input value)±1 digit Ambient temperature: 0 to 55°C When K type thermocouple input range 500°C or more, ±(0.7% of input value)±1 digit Measurement accuracy differs depending on the type of input, and the input |
| Temperature sensor/Temperature control - Cold contact temperature compensation error | Within ±1.0°C (When ambient temperature is 0 to 55°C) However, within ± 2.0°C while input value is -150 to -100°C / within ± 3.0°C while input value is -200 to -150°C |
| Temperature sensor/Temperature control - Sampling period | 250 ms/4ch |
| Temperature sensor/Temperature control - Input impedance | 1 MΩ or more |
| Temperature sensor/Temperature control - Current detector (CT) input (Number of input points) | 4 points |
| Temperature sensor/Temperature control - Current detector (CT) input (Measurement precision) | Larger one between ±5% of input value and ±2 A (Excluding precision of current detector) |
| Temperature sensor/Temperature control - Current detector (CT) input (Current detector) | CTL-12-S36-8, CTL-12-S56-10, CTL-6-P-H (manufactured by U.R.D. Co., Ltd.) |
| Temperature sensor/Temperature control - Current detector (CT) input (Sampling period) | 0.5 sec. |
| Temperature sensor/Temperature control - Control operation period | 250 ms/4ch |
| Temperature sensor/Temperature control - Control system | Two-position control, PID control, Heating/cooling PID control, Cascade control |
| Temperature sensor/Temperature control - Temperature measuring range - K | -200 to 1300°C/-100 to 2400°F |
| Temperature sensor/Temperature control - Temperature measuring range - J | -200 to 1200°C/-100 to 2100°F |
| Temperature sensor/Temperature control - Temperature measuring range - T | -200 to 400°C/-300 to 700°F |
| Temperature sensor/Temperature control - Temperature measuring range - S | 0 to 1700°C/0 to 3200°F |
| Temperature sensor/Temperature control - Temperature measuring range - R | 0 to 1700°C/0 to 3200°F |
| Temperature sensor/Temperature control - Temperature measuring range - E | -200 to 1000°C/0 to 1800°F |
| Temperature sensor/Temperature control - Temperature measuring range - B | 0 to 1800°C/0 to 3000°F |
| Temperature sensor/Temperature control - Temperature measuring range - N | 0 to 1300°C/0 to 2300°F |
| Temperature sensor/Temperature control - Temperature measuring range - PLII | 0 to 1200°C/0 to 2300°F |
| Temperature sensor/Temperature control - Temperature measuring range - U | -200 to 600°C/-300 to 700°F |
| Temperature sensor/Temperature control - Temperature measuring range - L | 0 to 900°C/0 to 1600°F |
| Temperature sensor/Temperature control - Temperature measuring range - W5Re/W26Re | 0 to 2300°C/0 to 3000°F |
| Temperature sensor/Temperature control - Temperature measuring range - Micro voltage input | 0 to 10 mV DC, 0 to 100 mV DC |
| Temperature sensor/Temperature control - Temperature measuring range - Pt100 (3-wire) | -200 to 600°C/-300 to 1100°F |
| Temperature sensor/Temperature control - Temperature measuring range - JPt100 (3-wire) | -200 to 500°C/-300 to 900°F |
| Temperature sensor/Temperature control - Temperature measuring range - Pt1000 (2-wire/3-wire) | -200.0 to 650.0°C/-328 to 1184°F |
| Temperature sensor/Temperature control - Heater disconnection detection | Alarm is detected by buffer memory (Variable within range from 0.0 to 100.0 A.) |
| Temperature sensor/Temperature control - Self-diagnostics function | Adjustment data check, input value check, watch dog timer check. |
| Temperature sensor/Temperature control - Memory | Built-in EEPROM (Number of times of overwrite: 100,000 times) |
| Output specifications | / 4 points |
| No. of output points | NPN open collector transistor output |
| Output method | 5 to 24 V DC |
| Rated load voltage | 30 V DC or less |
| Maximum load voltage | 100 mA |
| Maximum load current | 0.1 mA or less |
| Leak current in OFF status | 1.5 V (when energized with 100 mA) |
| Max. voltage drop when ON | 0.5 to 100.0 sec. |
| Control output cycle | / 24 V DC +20% -15% 50 mA It is necessary to connect a 24 V DC power supply to the terminal block. |
| Power supply specifications | 5 V DC 160 mA The power is internally supplied from the 5 V DC power supply unit of the main unit. |
| Ambient temperature | 0 to 55°C (32 to 131 °F) when operating and -25 to 75°C (-13 to 167 °F) when stored |
| Ambient humidity | 5 to 95%RH (no condensation) when operating |
| Vibration resistance - Installed on DIN rail - Frequency: 10 to 57 Hz | Half amplitude: 0.035 mm Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Vibration resistance - Installed on DIN rail - Frequency: 57 to 150 Hz | Acceleration: 4.9 m/s 2 Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Vibration resistance - Direct installing - Frequency: 10 to 57 Hz | Half amplitude: 0.075 mm Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Vibration resistance - Direct installing - Frequency: 57 to 150 Hz | Acceleration: 9.8 m/s 2 Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Shock resistance | 147 m/s 2 Acceleration, Action time: 11 ms, 3 times by half-sine pulse in each direction X, Y, and Z |
| Noise resistance | By noise simulator at noise voltage of 1,000 Vp-p, noise width of 1 μs, rise time of 1 ns and period of 30 to 100 Hz |
| Dielectric withstand voltage | Between batch of all terminals and ground terminal: 500 V AC for 1 min |
| Insulation resistance | Between batch of all terminals and ground terminal: 5 MΩ or higher by 500 V DC insulation resistance tester |
| Grounding | Class D grounding (grounding resistance: 100 Ω or less) (Common grounding with a heavy electrical system is not allowed) Ground the PLC independently or jointly. |
| Working atmosphere | Free from corrosive or flammable gas and excessive conductive dusts |
| Working altitude | 2000 m or less Do not use the PLC under pressure higher than the atmospheric pressure. Doing so may damage the PLC. |
FX5U, FX5UC, FX3U (V2.20 and later), FX3UC (V2.20 or later) [Connecting to the FX5U, FX5UC CPU module] FX5-CNV-BUS or FX5-CNV-BUSC is required to connect to the FX5U/FX5UC CPU module. Select one of th
