MELSEC-F Series FX3U-422-BD
| Applicable PLC | FX3U, FX3UC-32MT-LT(-2) |
| Number of occupied I/O points | 0 point (This number is not related to the maximum number of input/output points of the PLC.) |
| Communication method | Half-duplex, bidirectional communication |
| Communication speed | 9600/19200/38400/57600/115200 (bps) |
| Communication format | Programming communication |
| Transmission standard | Conforming to RS-422 |
| Transmission distance | 50 m maximum |
| Connection method | 8-pin MINI-DIN (female) |
| Isolation method | Non-isolated (between communication line and CPU) |
| Power supply specifications | / 5 V DC 20 mA (internal power supply from PLC main unit) |
| Ambient temperature | 0 to 55°C when operating and -25 to 75°C when stored |
| Ambient humidity | 5 to 95%RH (no condensation) when operating |
| Vibration resistance - Installed on DIN rail - Frequency: 10 to 57 Hz | Half amplitude: 0.035 mm Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Vibration resistance - Installed on DIN rail - Frequency: 57 to 150 Hz | Acceleration: 4.9 m/s 2 Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Vibration resistance - Direct installing - Frequency: 10 to 57 Hz | Half amplitude: 0.075 mm Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Vibration resistance - Direct installing - Frequency: 57 to 150 Hz | Acceleration: 9.8 m/s 2 Sweep Count for X, Y, Z: 10 times (80 min in each direction) |
| Shock resistance | 147 m/s 2 Acceleration, Action time: 11 ms, 3 times by half-sine pulse in each direction X, Y, and Z |
| Noise resistance | By noise simulator at noise voltage of 1,000 Vp-p, noise width of 1 μs, rise time of 1 ns and period of 30 to 100 Hz |
| Dielectric withstand voltage | Non-isolated between communication line and PLC main unit (Do not perform a withstand voltage test.) |
| Insulation resistance | Non-isolated between communication line and PLC main unit (Do not perform an insulation resistance test.) |
| Working atmosphere | Free from corrosive or flammable gas and excessive conductive dusts |
| Working altitude | 2000 m or less Do not use the PLC under pressure higher than the atmospheric pressure. Doing so may damage the PLC. |
0 point (This number is not related to the maximum number of input/output points of the PLC.)
