Amplifier Unit, DC Type, NPN ES-X38
| Model | |
| ES-X38; Type | |
| DC; Operation mode | |
| N.O./N.C. (switch-selectable); Indicator | |
| Output | Red LED; Output |
| Control output | |
| NPN | 100 mA (40 V) max. Residual voltage: 1 V max.; Disconnection alarm output |
| NPN | 100 mA (40 V) max. Residual voltage: 1 V max.; Leakage current (OFF time) |
| ―; Response time | |
| 1 ms max.; Temperature characteristics | |
| ±8% of detecting distance at 23°C 73.4°F , within 0 to 50°C 32 to 122°F; Sensitivity adjustment | |
| 15-turn trimmer; Rating | |
| Power voltage | |
| 12 to 24 VDC, Ripple (P-P) 10 % or less; Current/power consumption | |
| 25 mA max.; Environmental resistance | |
| Ambient temperature | |
| 0 to +50 °C 32 to 122 °F; Relative humidity | |
| 35 to 85 % RH (No condensation); Weight | |
| Approx. 67 g (including 2-m 6.6' cable) | |
ES-X38, Amplifier Unit, DC Type, NPN in ES series by KEYENCE America.
