Amplifier Unit, Main Unit, PNP ES-M1P
| Model | |
| ES-M1P *1; Type | |
| One-line expansion system; Shape | |
| Main unit; Operation mode | |
| N.O./N.C. switch-selectable; Timer function | |
| 10-ms delay / timer OFF switchable *2; Output | |
| PNP; Output | |
| Control output | |
| PNPopen collector 100 mA max. 26.4 V, residual voltage 1 V max.; Disconnection alarm output | |
| PNPopen collector 100 mA max. 26.4 V, residual voltage 1 V or less *3; Response time | |
| 1 ms max.; Temperature characteristics | |
| Within ±8% of detecting distance at +23°C 73.4°F when within 0 to 50°C 32 to 122°F temperature range; Sensitivity adjustment | |
| 25-turn trimmer; Protection circuit | |
| Reverse power connection protection, output overcurrent protection, output surge protection; Rating | |
| Power voltage | |
| 12 to 24 VDC, Ripple (P-P) 10 % or less; Current/power consumption | |
| 25 mA max.; Environmental resistance | |
| Ambient temperature | |
| 0 to +50 °C 32 to 122 °F *4; Relative humidity | |
| 35 to 85 % RH (No condensation); Weight | |
| Approx. 65 g (including nuts and 2-m 9.8' cable); *1 The ES-M1(P)/M2(P) cannot be connected to the EH-422, 430, 440 or 290. *2 During N.O. operating configuration, the off delay timer is 10 ms. During N.C., the on delay timer is 10 ms. *3 Broken connection warning output is not available on the ES-M2 (P). *4 The ambient temperature changes according to the following conditions when expansion units are added. When adding units, always attach them to a DIN rail (metal plate) and set the output current to 20 mA or less. 1 to 10 expansion units | 0 to 50˚C 32 to 122˚F 11 to 16 expansion units: 0 to 45˚C 32 to 113˚F |
ES-M1P, Amplifier Unit, Main Unit, PNP in ES series by KEYENCE America.
