Schneider Electric C63F42D630 | Industrial Automation Component

SKU: C63F42D630
(2)
$714.10
-13% $821.21 $714.10
In stock
Usually ships within 24 hours
Condition
Factory pre-tested, ready for instant commissioning！

All industrial automation equipment comes complete with standard matching accessories and detailed step-by-step commissioning manuals. Unbox, install and commission your automation projects smoothly with full confidence.

Free shipping
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

Email +86 18017464056

C63F42D630 Schneider Electric - ComPacT NSX630F Circuit Breaker with MicroLogic 2.3 Trip Unit. ComPacT NSX630F series 4-pole molded case circuit breaker rated for 630A with 36 kA breaking capacity at 415V. Equipped with MicroLogic 2.3 electronic trip unit providing adjustable long time, short time, and fixed instantaneous protection functions.

  • Brand: Schneider Electric
  • Category: Molded Case Circuit Breaker
  • Series: ComPacT NSX
  • Product Type: Molded case circuit breaker (with trip unit)
  • Number of Poles: 4 (4P4D)
  • Rated Current: 630 A at 40 degrees C
  • Breaking Capacity Code: F (36 kA at 415V)
  • Breaking Capacity at 220/240V: 40 kA
  • Breaking Capacity at 380/415V: 36 kA
  • Breaking Capacity at 440V: 30 kA
  • Breaking Capacity at 690V: 10 kA
  • Rated Voltage: 690 V AC 50/60 Hz
  • Insulation Voltage: 800 V AC
  • Impulse Withstand Voltage: 8 kV
  • Trip Unit: MicroLogic 2.3 (electronic)
  • Trip Unit Protection: LSOI (Long time, Short time, Instantaneous)
  • Control Type: Toggle switch
  • Mounting: Fixed
  • Weight: 6.2 kg
  • Dimensions (W x H x D): 140 x 255 x 110 mm
  • Standards: EN/IEC 60947-2, CCC, EAC

Designed for industrial power distribution systems requiring advanced electronic protection. The MicroLogic 2.3 trip unit provides precise adjustable protection for distribution systems, motor circuits, and critical infrastructure applications.

Place your order before 14:00 for earliest possible shipment handover. With round-the-clock transit operated by our partnered global logistics providers, parcels reach most international destinations following routine customs processing. Normal delivery takes 2–6 business days subject to customs clearance progress.Shipping fees will be charged for all orders under USD 500, and the exact shipping cost will be determined and collected by our logistics carriers. Shipments to remote international regions will incur additional courier surcharges to offset extra cross-border transportation costs.

Factory warranty service is not applicable to this industrial control equipment, and extended warranty packages are not provided for this item.
★ ★ ★ ★ ★
4.0 / 5 (2 review)
