BMXDRC0805 Schneider Electric - Modicon X80 Relay Output Module - 8 Channels NO/NC Type C. Modicon X80 discrete relay output module with 8 NO/NC Type C isolated relay outputs. Supports 5-125 VDC and 24-240 VAC output voltage range with 4A thermal current per channel. Features 40-way terminal block connection and integrated channel diagnostics.

  • Brand: Schneider Electric
  • Category: PLC I/O Module
  • Series: Modicon X80
  • Product Type: Relay discrete output module
  • Number of Outputs: 8
  • Output Type: Relay (NO/NC Type C, isolated)
  • Output Voltage: 5-125 V DC, 24-240 V AC
  • Thermal Current per Channel: 4 A at 40 degrees C, 3 A at 50 degrees C, 2 A at 60 degrees C
  • Insulation Resistance: >10 MOhm at 500 V DC
  • Power Dissipation: 3.6 W
  • Response Time: <=10 ms activation, <=13 ms deactivation
  • Minimum Switching Current: 10 mA at 5 V DC
  • Electrical Connection: 40-way terminal block
  • Current Consumption: 40 mA at 3.3 V DC, 101 mA at 24 V DC
  • MTBF Reliability: 2,683,411 hours
  • Protection Rating: IP20
  • Operating Temperature: 0 to 60 degrees C
  • Status LEDs: RUN (green), ERR (red), I/O (red), 1 per channel (green)
  • Standards: EN/IEC 61131-2

Designed for Modicon M340 and M580 PLC systems requiring relay output control. Suitable for driving contactors, solenoid valves, motors, and other industrial actuators in manufacturing, process control, and machinery automation applications.
