Schneider Electric BMXDAI0805 | Industrial Automation Component

BMXDAI0805 Schneider Electric - Modicon X80 Discrete AC Input Module, 8 Channels, 200-240V AC, Isolated. Discrete input module for Modicon X80 platform with 8 isolated AC inputs rated at 200-240V AC. Uses capacitive input type technology with galvanic isolation between channels and bus. Features fast activation (10ms) and deactivation (20ms) filtering times with per-channel diagnostic LEDs.

• Brand: Schneider Electric
• Category: Discrete Input Module
• Product Type: Discrete Input Module
• Range of Product: Modicon X80
• Series: BMXD
• Discrete Input Number: 8
• Discrete Input Type: Isolated
• Input Type: Capacitive
• Discrete Input Voltage: 200...240 V AC
• Network Frequency: 50/60 Hz (47...63 Hz limits)
• Discrete Input Current: 10.4 mA
• Input Impedance: 21000 Ohm
• Input Compatibility: 2-wire/3-wire proximity sensors IEC 60947-5-2, IEC 61131-2 Type 2
• Current State 1 Guaranteed: >= 6 mA
• Current State 0 Guaranteed: <= 4 mA
• Sensor Power Supply: 170...264 V
• AC Activation Response Time: 10 ms
• AC Deactivation Response Time: 20 ms
• Insulation Resistance: > 10 MOhm at 500 V DC
• Dielectric Strength: 1500 V AC 50/60 Hz 1 min
• Power Dissipation: 4.73 W
• Current Consumption: 76 mA at 3.3V DC (typical), 93.6 mA at 24V DC (typical)
• Protection Type: 1 external fuse per group, 0.5 A fast blow
• Voltage Detection Threshold: > 164 V AC (sensor OK), < 80 V AC (sensor fault)
• Local Signalling: 1 LED green (RUN), 1 LED per channel green (diagnostic), 1 LED red (ERR), 1 LED red (I/O)
• MTBF Reliability: 1700000 hours
• Net Weight: 0.12 kg (0.26 lb)
• IP Degree of Protection: IP20
• Operating Temperature: 0...60°C
• Storage Temperature: -40...85°C
• Relative Humidity: 5...95% at 55°C without condensation
• Operating Altitude: 0...2000 m (up to 5000 m with derating)
• Vibration Resistance: 3 gn
• Shock Resistance: 30 gn
• Country of Origin: France
• RoHS Compliant: Yes
• Directives: 2014/35/EU (LVD), 2014/30/EU (EMC)

Monitors 8-channel AC digital inputs from 200-240V AC field devices such as proximity sensors, push buttons, and limit switches in industrial automation, process control, and substation monitoring applications using Modicon M340 and M580 PLC platforms.
