BMXAMM0600H Schneider Electric - Modicon X80 Mixed Analog I/O Module 4 Inputs 2 Outputs (H Version). The Schneider Electric BMXAMM0600H is a ruggedized mixed analog I/O module for Modicon X80 platform with 4 fast input channels and 2 output channels. The H version features conformal coating for severe environments.

  • Brand: Schneider Electric
  • Category: PLC I/O Modules
  • Brand: Schneider Electric
  • Product Range: Modicon X80
  • Product Type: Mixed Analog I/O Module
  • Number of Inputs: 4 (fast)
  • Number of Outputs: 2
  • Input Types: Voltage +/-10V (14-bit), 0-10V (13-bit), 0-5V (12-bit), 1-5V (12-bit), Current 0-20mA (12-bit), 4-20mA (12-bit)
  • Output Types: Voltage +/-10V (12-bit), Current 0-20mA (11-bit), 4-20mA (11-bit)
  • Resolution: 12-bit (up to 14-bit for +/-10V input)
  • Fast Read Cycle: 1 ms + 1 ms x number of channels industrial
  • Nominal Read Cycle: 5 ms for 4 channels
  • Conversion Time (Output): <= 2 ms
  • Input Impedance: 250 Ohm
  • Measurement Error: 0.25% of full scale at 25 degrees C (input), 0.25% (output)
  • MTBF: 1,400,000 hours
  • Protective Treatment: Conformal coating (H version)
  • IP Rating: IP20
  • Operating Temperature: -25 to 70 degrees C
  • Net Weight: 0.155 kg
  • Power Consumption: 2.6W typical at 24V DC
  • Current Consumption: 240 mA at 3.3V DC
  • Fallback Mode: Configurable
  • Certifications: CE, UL, CSA, RCM, EAC, ATEX, IEC-Ex
  • Standards: EN/IEC 61131-2, EN/IEC 61010-2-201
  • Warranty: 18 months

Suitable for industrial automation applications requiring combined analog input and output in a single module. Ideal for process control, closed-loop regulation, and sensor/actuator interfacing in severe environments using Modicon M580 or M340 PACs.
