Allen-Bradley 1762-IR4 | Industrial Automation Component

MicroLogix 4 Point Module

1762 MicroLogix 1200 System, MicroLogix 4 Point Module

Specifications

• Class: Progmable Logic Controller
• Depth: 87
• Height: 90
• I/O Isolation: Isolated
• I/O Status Indication: LED
• Module Interfaces: resistance thermom
• Number Of Channels: 4 point
• Temperature Rating: 0¡­55 ¡ãC (32¡­131 ¡ãF)
• Thermocouple Type: 4 Channel, RTD/Resistance Module
• Accuracy drift: At 0...55 ¡ãC ¡À0.026 ¡ãC/¡ãC (0.026 ¡ãF/¡ãF) for Pt 385, ¡À0.007 ?/¡ãC (0.012 ?/¡ãF) for 150 ? range, ¡À0.023 ¡ãC/¡ãC (0.023 ¡ãF/¡ãF) for Pt 3916, ¡À0.023 ?/¡ãC (0.041 ?/¡ãF) for 500 ? range, ¡À0.012 ¡ãC/¡ãC (0.012 ¡ãF/¡ãF) for Ni, ¡À0.043 ?/¡ãC (0.077 ?/¡ãF) for 1,000 ? range,
• A/D converter type: Delta-Sigma
• Analogue inputs configurable: false
• Analogue outputs configurable: false
• Bus current draw: 50mA @ 24V DC, maximum
• Cable impedance: Maximum @ 25 ? (operating with >25 ? will reduce accuracy)
• Calibration: The module performs autocalibration on channel enable and on a configuration change between channels. You can also prog the module to calibrate every five minutes
• Channel diagnostics: Over or under range or open circuit condition by bit reporting for analog inputs
• Channel to channel isolation: ¡À10V DC
• Common mode rejection: >110 dB at 60 Hz (with 10 or 60 Hz filter)
• Conducted immunity: IEC 1000-4-6: 10 V/m, 80...1000 MHz, 80% Alitude modulation, +900 MHz keyed carrier
• ESD immunity: IEC1000-4-2: 4kV contact, 8kV air, 4kV indirect
• Excitation current source: 0.5 mA and 1.0 mA selectable per channel
• Fast transient burst: IEC1000-4-4: 2kV @ 5kHz
• Hazardous environment class: Class I, Division 2, Hazardous Location, Groups A, B, C, D (UL 1604, C-UL under CSA C22.2 No. 213)
• Heat dissipation: 1.5 total W (the W per point, plus the minimum W, with all points enabled)
• Input and output group to system isolation: 30V AC/30V DC working voltage type test: 500V AC or 707V DC @ 1min
• Input channel configuration: Via configuration software screen or the user prog (by writing a unique bit pattern into the module¡¯s configuration file)
• Input, current: false
• Input impedance: >10 M?
• Input, resistance thermometer: false
• Input, resistor: true
• Input signal, configurable: true
• Input, thermocouple: false
• Input type: 604 ? Nickel-Iron 518
• Input, voltage: false
• Module power LED: ON: indicates power is applied
• Non-linearity: ¡À0.05% (in % full scale)
• Normal mode rejection ratio: 70 dB minimum @ 60 Hz with the 10 or 60 Hz filter selected
• Number of analogue inputs: 4
• Open-circuit detection time: 6 ms
• Operating altitude: 2000 m
• Operating humidity: 5...95% noncondensing
• Operating temperature: -20 ¡ãC
• Output, current: false
• Output signal configurable: false
• Output, voltage: false
• Overload at input terminals: Maximum @ ¡À35V DC continuous
• Power supply distance rating: 6 (the module may not be more than 6 modules away from the system power supply)
• Radiated and conducted emissions: EN50081-2: Class A
• Radiated immunity: IEC 61000-4-3: 10 V/m, 80...1000 MHz, 80% Alitude modulation, +900 MHz keyed carrier
• Recommended cable: Belden 8761 (shielded)
• Repeatability: ¡À0.2 ? for other resistances
• Resolution: Input filter and configuration dependent
• Shipping weight, approx: 260 g
• Shock: Operating: 30 G
• Storage temperature: -40 ¡ãC
• Suitable for safety functions: false
• Surge immunity: IEC1000-4-5: 1kV galvanic gun
• Type of electric connection: Screw connection
• Typical accuracy: At 25 ¡ã C (77 ¡ãF) ambient with module operating temperature at 25 ¡ãC (77 ¡ãF)
• Typical overall accuracy: ¡À0.5 ¡ãC (¡ãF) for Pt 385
• Update time: Input filter and configuration dependent (typical)
• Vibration: Operating: 10...500 Hz, 5 G, 0.030 in @ maximum peak-to-peak
• Width: 40 mm
