Allen-Bradley 1762-IQ16 | Industrial Automation Component

SKU: 1762-IQ16
(2)
$207.00
In stock
Usually ships within 24 hours
Factory pre-tested, ready for instant commissioning！

All industrial automation equipment comes complete with standard matching accessories and detailed step-by-step commissioning manuals. Unbox, install and commission your automation projects smoothly with full confidence.

Free shipping
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

Email +86 18017464056

MicroLogix 16 Point Digital Input Module

1762 MicroLogix 1200 System, 16 Point 24 VDC Sink/Source Input Module

Specifications

  • Class: Progmable Logic Controller
  • Depth: 87
  • digital input modules: 16 Point 24V DC Sink/Source
  • Height: 90
  • I/O Isolation: Isolated
  • I/O Status Indication: LED
  • Module Interfaces: digital input
  • Number Of Channels: 16 point
  • Temperature Rating: -20¡­65 ¡ãC (-4¡­149 ¡ãF)
  • Altitude: 2000 m
  • Bus current draw, max: 70mA @ 5V DC (0.35 W)
  • Conducted RF immunity: IEC 1000-4-6: 10V @ 0.15...80MHz
  • Digital inputs configurable: false
  • Digital outputs configurable: false
  • EFT/B immunity: IEC1000-4-4: 2kV @ 5kHz
  • ESD immunity: IEC1000-4-2: 4kV contact, 8kV air, 4kV indirect
  • Hazardous environment class: Class I, Division 2, Hazardous Location, Groups A, B, C, D (UL 1604, C-UL under CSA C22.2 No. 213)
  • Heat dissipation, max: 5.4 W @ 30V
  • IEC input compatibility: Type 1+
  • Input group to backplane isolation: Verified by one of the following dielectric tests: 1200V AC @ 1s or 1697V DC @ 1s 75V DC working voltage (IEC Class 2 reinforced insulation)
  • Isolated groups: Group 1: inputs 0...7, Group 2: inputs 8...15
  • Nominal Impedance: 3 k?
  • Number of commons: 2
  • Number of digital inputs: 16
  • Off-state current, max: 1.5 mA
  • Off-state voltage, max: 5V DC
  • ON-state current, max: 12.0mA @ 30V DC
  • On-state current, min: 2.0mA @ 10V DC
  • On-state current, nom: 8.0mA @ 24V DC
  • On-state voltage, min: 10V DC
  • Operating humidity: 5...95% noncondensing
  • Operating temperature: -20 to 65 ¡ãC
  • Operating voltage: 10¡­30V DC 10¡­26.4V DC
  • Power supply distance rating: 6 (the module may not be more than 6 modules away from the system power supply)
  • Radiated and conducted emissions: EN50081-2: Class A
  • Radiated RF immunity: IEC1000-4-3: 10 V/m, 80...1,000 MHz, 80% Alitude modulation, +900 MHz keyed carrier
  • Redundancy: false
  • Shock: Operating: 30G panel mounted, 3 pulses per axis, Relay ops: 7G
  • Short-circuit protection, outputs available: false
  • Signal delay: On delay: 8.0 ms
  • Storage temperature, min: -40 ¡ãC
  • Suitable for safety functions: false
  • Surge transient immunity: IEC1000-4-5: 2 kV common mode, 1kV differential mode
  • Time delay at signal exchange: 8 ms
  • Type of electric connection: Screw connection
  • Type of voltage (input voltage): DC
  • Vibration: Operating: 10 to 500 Hz, 5G, 0.030 in. max. peak-to-peak, 2 hr per axis Relay ops : 1.5G
  • Voltage category: 24V DC sink/source
  • Weight: 230 g
  • Width: 40.4 mm
