Allen-Bradley 1762-IF4 | Industrial Automation Component

MicroLogix 4 Point Analog Input Module

1762 MicroLogix 1200 System, 4 Channel Current/Voltage Analog Input Module

Specifications

• analog input modules: 4 Channel Current/Voltage Analog Input Module
• Class: Progmable Logic Controller
• Current Range: 4-20
• Depth: 87
• Height: 90
• I/O Isolation: Isolated
• I/O Status Indication: LED
• Module Interfaces: analog input
• Number Of Channels: 4 point
• Temperature Rating: -20¡­65 ¡ãC (-4¡­149 ¡ãF)
• A/D converter type: Successive approximation
• Analog normal operating range: Voltage: -10...10V DC
• Analogue inputs configurable: true
• Analogue outputs configurable: false
• Bus current draw, max: 40mA @ 5V DC, 50mA @ 24V DC
• Channel diagnostics: Over or under range or open circuit condition by bit reporting for analog inputs
• Common mode rejection: >55 dB at 50 and 60 Hz
• Common mode voltage range: -27 to 27V
• Conducted immunity: 10V @ 0.15...80MHz
• Current input protection: -32 mA
• ESD immunity: EN 61000-4-2, 4 kV contact, 8 kV air, 4 kV indirect
• Fast transient burst: IEC1000-4-4: 2kV @ 5kHz
• Full scale analog ranges: Voltage: -10.5...10.5V DC, Current: -21...21 mA
• Hazardous environment class: Hazardous Location, Class I, Division 2 Groups A, B, C, D (UL 1604, C-UL under CSA C22.2 No. 213)
• Input and output group to system isolation: 30V AC/30V DC rated working voltage (N.E.C. Class 2 required) (IEC Class 2 reinforced insulation) type test: 500V AC or 707V DC @ 1min
• Input, current: true
• Input impedance: Voltage Terminal: 200 K?
• Input, resistance thermometer: false
• Input, resistor: false
• Input signal, configurable: true
• Input, thermocouple: false
• Input update time: Typical: 130, 250, 290, 450, 530 ms (selectable)
• Input, voltage: true
• Module power LED: On: indicates power is applied
• Non-linearity: ¡À0.12% (in % full scale)
• Number of inputs: 4 differential (bipolar)
• Operating altitude: 2000 m
• Operating humidity: 5...95% noncondensing
• Operating temperature: -20 ¡ãC
• Output, current: false
• Output signal configurable: false
• Output, voltage: false
• Radiated and conducted emissions: EN50081-2: Class A
• Radiated immunity: IEC1000-4-3: 10 V/m, 80...1,000 MHz, 80% Alitude modulation, +900 MHz keyed carrier
• Recommended cable: Belden 8761 (shielded), (For 1762-IT4, shielded thermocouple extension wire for the specific type of thermocouple you are using. Follow thermocouple manufacturer¡¯s recommendations.)
• Repeatability: -0.12 to 0.12%
• Resolution of the analogue inputs: 15 bit
• Shock: Operating: 30 g
• Storage temperature: -40 ¡ãC
• Surge immunity: IEC1000-4-5: 1kV galvanic gun
• Type of electric connection: Screw connection
• Typical overall accuracy: ¡À0.32% full scale @ -20...65 ¡ãC, ¡À0.24% full scale @ 25 ¡ãC
• Vibration: Operating: 5 g @ 10...500 Hz, 0.030 in. max. peak-to-peak
• Voltage input protection: -30 V
• Weight: Shipping: 240 g (0.53 lbs.) approximately (with cartoon)
• Width: 40 mm
