A9 3-Pole Power Contactor
| General | |
|---|---|
| Product Type | 3-Pole Power Contactor |
| Model Designation | A9-30-10 |
| Number of Main Poles | 3 (3 NO) |
| Auxiliary Contacts (built-in) | 1 NO |
| Terminal Type | Screw Terminals |
| Electrical Ratings | |
| Rated Operational Current AC-3 (400 V) | 9 A |
| Rated Operational Current AC-3 (230 V) | 9 A |
| Rated Operational Current AC-1 (690 V) | 25 A |
| Rated Operational Power AC-3 (400 V) | 4 kW |
| Horsepower Rating UL/CSA (480 V) | 5 hp |
| Rated Operational Voltage (Main) | 690 V AC / 220 V DC |
| Rated Insulation Voltage (Ui) | 690 V (IEC) / 600 V (UL/CSA) |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Coil | |
| Rated Control Circuit Voltage (Uc) | 220-230 V 50Hz / 230-240 V 60Hz (AC) |
| Coil Technology | Electronic (AF) — AC/DC wide range |
| Physical | |
| Dimensions (W × H × D) | 45 × 86 × 77 mm |
| Weight | 0.35 kg |
| Degree of Protection | IP20 |
| Mounting | DIN Rail (TH35-15) or Screw Mounting |
| Operating Temperature | -40 ... +70 °C (compensated: -25 ... +60 °C with O/L relay) |
| Utilization Categories | |
| Max Electrical Switching Freq. AC-3 | 1200 cycles/hour |
| Max Electrical Switching Freq. AC-1 | 600 cycles/hour |
| Mechanical Switching Frequency | 3600 cycles/hour |
| Standards | IEC/EN 60947-1, IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 |
| RoHS | Compliant (EU Directive 2011/65/EU) |
| UL/CSA | Listed — cURus |
| CE Marking | Yes — Low Voltage Directive |
| Marine Approvals | ABS, DNV, Lloyd's Register, RINA |
| Condition | New & Original Packaging |
A: This power contactor comes with manufacturer warranty. Contact us for specific warranty terms.
A: Orders placed before 14:00 ship same day. Standard delivery: 5-8 business days worldwide. Express available.
A: Yes, 1SBL143061R5110 is designed for full compatibility with ABB ecosystem. Contact our technical team for integration support.
Place your order before 14:00 for earliest possible shipment handover. With round-the-clock transit operated by our partnered global logistics providers, parcels reach most international destinations following routine customs processing. Economy shipping takes 5–8 business days, while express delivery arrives in 5–8 business days, both subject to customs clearance progress.Shipping fees will be charged for all orders under USD 500, and the exact shipping cost will be determined and collected by our logistics carriers. Shipments to remote international regions will incur additional courier surcharges to offset extra cross-border transportation costs.
Factory warranty service is not applicable to this industrial control equipment, and extended warranty packages are not provided for this item.
