The CM579-ETHCAT is an EtherCAT master communication module for the ABB AC500 PLC family. It allows the AC500 controller to manage up to 126 EtherCAT slave devices (drives, remote I/O, encoders and valves) in a high-performance motion and I/O network on one controller.
Data exchange per EtherCAT station reaches 128 bytes in each direction, with a minimum cycle time of 2 ms and bus-cycle times starting at 250 µs. The module provides two RJ45 EtherCAT ports, and is configured from within Control Builder Plus / PS501 with no separate configuration tool.
It runs from the 24 V DC PLC supply, supports a maximum cable length of 100 m between nodes and mounts on the AC500 communication-module rail with IP20 protection.
| Product ID | 1SAP170902R0101 |
| ABB Type Designation | CM579-ETHCAT |
| Product Series | AC500 communication modules |
| Function | EtherCAT master for motion control and remote I/O |
| Protocol | EtherCAT (100 Mbit/s) |
| Max. Number of Slaves | Up to 126 |
| Data Length per Slave | 128 bytes input / 128 bytes output |
| Min. EtherCAT Cycle Time | 250 µs bus cycle / 2 ms task cycle |
| Max. Cable Length | 100 m between nodes |
| Interfaces | 2 × RJ45 EtherCAT ports |
| Configuration | In Control Builder Plus / PS501 |
| Supply Voltage | 24 V DC |
| Degree of Protection | IP20 (cabinet installation) |
| Mounting | 35 mm DIN rail (TH35) |
| Ambient Temperature (Operation) | −25 °C … +55 °C |
| Dimensions (W×H×D) | 35 × 110 × 76 mm |
