| Parameter | Value |
|---|---|
| Product Type | AC Machinery Drive |
| Series / Model | ACS180-04N |
| Rated Power | 4 kW (400V) |
| Rated Current | 9.4 A (400V) |
| Input Voltage | 380-480V, 3-phase |
| Frame Size | R2 |
| Protection Class | IP20 |
| Communication | Modbus RTU (built-in); micro-console port |
| I/O Configuration | 2 AI, 4 DI, 1 DO (transistor), 1 relay |
| Control Voltage | Scalar / Sensorless vector |
| Efficiency | IE2, 98% |
| Weight | ~1.5 kg |
| Dimensions | Compact module |
| Safety Function | No STO (N variant) |
Variable frequency control optimizes motor speed to match actual load requirements, significantly reducing energy consumption.
Intuitive control panel with application-specific assist menus. Optional Bluetooth connectivity for remote setup.
Built-in protection for overcurrent, overvoltage, undervoltage, earth fault, and motor thermal overload.
Built-in Modbus with optional fieldbus adapters for PROFINET, PROFIBUS, EtherNet/IP, BACnet, and more.
IEC 61131-2, IEC 60947 series. CE, UL, cUL certified. RoHS compliant per EU Directive 2011/65/EU.
Operating: -25 to +60°C. Storage: -40 to +70°C. Protection: IP20.
