ABB A26-30-01 230-240V 50Hz / 240-260V 60Hz Motor Protection / Control Device - Industrial Automation Part
ABB A26-30-01 230-240V 50Hz / 240-260V 60Hz Motor Protection / Control Device - Industrial Automation Part

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

ABB

ABB 1SBL241001R8801

SKU: 1SBL241001R8801
(0)
$96.18
In stock
Usually ships within 72 hours
Condition
Factory pre-tested, ready for instant commissioning！

All industrial automation equipment comes complete with standard matching accessories and detailed step-by-step commissioning manuals. Unbox, install and commission your automation projects smoothly with full confidence.

Free shipping
100% secure payments
Industry leading quality

Got questions?

Feel free to get in touch

Ask an expert!

+86 18017464056
AF Series Contactor

1SBL241001R8801

ABB AF40 AF Series 3-Pole Contactor with 1 NC (mirror contact) Auxiliary Contacts

Model: AF40-30-01 AC-3: 18.5 kW @ 400V Ith: 65 A UL/CSA: 60 A @ 600V Coil: 100-250V AC/DC

Key Ratings at a Glance

AC-3 Power @ 400V
18.5 kW
AC-3 Current @ 400V
37 A
AC-1 @ 690V (40°C)
60 A
UL/CSA @ 600V
60 A
Thermal Current Ith
65 A
HP Rating @ 480V
30 hp
Main Poles
3P NO
Aux Contacts
0NO+1NC

Technical Specifications

Electrical Ratings

Parameter Value
Rated Operational Voltage 690 V (Main Circuit)
Rated Control Circuit Voltage 100...250 V AC / 100...250 V DC
Rated Frequency 50/60 Hz
Conventional Thermal Current (Ith) 65 A @ 40°C (free air)
Rated Insulation Voltage 690 V
Impulse Withstand Voltage 6 kV
Number of Main Contacts NO 3
Number of Main Contacts NC 0
Auxiliary Contacts 1 NC (mirror contact)

Current Ratings

Category Conditions Value
AC-1 690V, 40°C 60 A
AC-1 690V, 60°C 50 A
AC-3 380/400V, 55°C 37 A
AC-3 440V, 55°C 37 A
AC-3 500V, 55°C 32 A
AC-3 690V, 55°C 23 A
UL/CSA General Use 600V AC 60 A

Power Ratings (AC-3)

Voltage Power
220/230/240 V 10.2 kW
380/400 V 18.5 kW
415 V 19.2 kW
440 V 20.4 kW
500 V 23.1 kW
690 V 31.9 kW

Mechanical Data

Parameter Value
Dimensions (W×D×H) 55 × 108 × 90 mm
Net Weight 0.71 kg
Terminal Type Screw Terminals
Main Connection Rigid 6...35 mm² / Flexible 4...35 mm²
Max Operating Altitude 3000 m
Degree of Protection IP20 / IP10 (main terminals)
Mounting DIN rail (35mm) or screw

Applications & Features

Typical Applications

  • 3-phase motor control and starting
  • Motor reversing and star-delta starting
  • Capacitor switching for power factor correction
  • Lighting circuit control
  • Heating and resistive load switching
  • Bypass circuits for soft starters and VFDs
  • Industrial automation and process control

Key Features

  • Wide Voltage Range: 100...250 V AC / 100...250 V DC — one coil covers multiple global voltages
  • AC/DC Universal: Single coil for both AC and DC operation
  • Built-in Surge Suppression: No additional suppressors required
  • Reliable Operation: Distinct closing and opening, noise-free
  • Voltage Dip Tolerance: Withstands supply interruptions ≤ 20ms
  • 80% Lower Energy: Reduced coil holding consumption vs conventional contactors
AF Technology: ABB AF contactors feature an integrated electronic coil interface that accepts a wide control voltage range. Only 4 coil variants cover voltages from 24V to 500V AC/DC, dramatically reducing inventory requirements. The built-in surge suppression eliminates the need for external suppressors, saving space and cost.

Compliance & Approvals

Standard Details
IEC / EN Standards IEC/EN 60947-1, IEC/EN 60947-4-1
UL Listed UL 508
CSA Certified CSA C22.2 No. 14
RoHS Compliant per EU Directive 2011/65/EU
Marine / Railway IEC 60077, EN 50155, IEC 61373 (as applicable)
Climatic Withstand Category B per IEC 60947-1 Annex Q
Operating Temperature -40°C to +70°C (without O/L relay) / -25°C to +60°C (with O/L relay)
Max Switching Freq. AC-3: 1200 cycles/hr | Mechanical: 3600 cycles/hr

ABB AF40-30-01 | Order Code: 1SBL241001R8801 | Authorized Distributor - SHLY-PLC

Product specifications sourced from ABB official catalog data. Contact us for custom configurations and volume pricing.
