ABB SD202/32 2-pole switch disconnector rated at 32 A, providing safe isolation and load switching for low-voltage distribution circuits with 25 kA short-circuit withstand capacity.
| Product Type | Switch Disconnector |
| Model | SD202/32 |
| Order Code | 2CDD282101R0032 |
| Number of Poles | 2 |
| Rated Current (In) | 32 A |
| Rated Operational Voltage (Ue) | 440 V AC / 125 V DC |
| Rated Insulation Voltage (Ui) | 440 V AC |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV (6.2 kV at sea level) |
| Rated Conditional Short-Circuit Current | 25 kA |
| Rated Frequency | 50/60 Hz, DC |
| Utilization Category | AC-23A, DC-21A |
| Standards | IEC/EN 60947-3 |
| Electrical Endurance (AC) | 10,000 cycles |
| Mechanical Endurance | 20,000 cycles |
| Power Loss per Device | 3.63 W |
| Actuator Type | Toggle |
| Contact Position Indication | Red ON / Green OFF (Real CPI) |
| Terminal Type | Cylinder-lift screw terminals |
| Terminal Capacity | 0.75-35 mm² |
| Busbar Capacity | 10 mm² |
| Tightening Torque | 2.8 N·m |
| Mounting Type | DIN rail (TH35) |
| Degree of Protection | IP20 (IP40 with cover) |
| Overvoltage Category | III |
| Pollution Degree | 3 |
| Ambient Temperature (Operation) | -25 to +55 °C |
| Dimensions (W×H×D) | 35.0 × 88 × 69 mm |
| Weight | 0.17 kg |
| Approvals | CE, VDE, CCC, EAC, KEMA |
